ENGLISH
Insert part R (rawlplug) into holes F and
screw hook G into part R (Fig. 3).
INJECTORS TABLE
Type of gas Type of
used burner
Natural gas triple ring
(Methane) rapid
G20 semirapid
auxiliary
Liquid triple ring
petroleum rapid
gas (cylinder) semirapid
G30 auxiliary
Liquid triple ring
petroleum rapid
gas (cylinder) semirapid
G31 auxiliary
Type of gas used Model
G20 20 mbar
G30 30 mbar
G31 30 mbar
ELECTRICAL POWER SUPPLY: 230 V ~ 50 Hz
2x
F
R
G
Fig. 3
Injector Nominal
marking heating
capacity
kW
130 3.60
1 15 3.00
97 1.75
72 1.00
76 3.60
75 3.00
58 1.75
43 1.00
76 3.60
75 3.00
58 1.75
43 1.00
Total nominal
configuration heating capacity
kW
5 burners 1 1.10
5 burners 1 1.10
5 burners 1 1.10
Secure the chain to hook G as shown in
Fig. 4 position C.
C
i
Class appliance: 1
Appliance Category II 2E3B/P (DE)
Nominal Reduced
consumption heat
capacity
kW
343 l/h 1.30
286 l/h 0.75
167 l/h 0.48
95 l/h 0.33
262 g/h 1.30
219 g/h 0.75
128 g/h 0.48
73 g/h 0.33
258 g/h 1.30
215 g/h 0.75
126 g/h 0.48
71 g/h 0.33
Total nominal
consumption
1058 l/h
810 g/h
796 g/h
2x
G
C
Fig. 4
II 2H3B/P (AT)
Gas pressure
mbar
min. rated max.
17 20
42.5 50
42.5 50
Air necessary (m
for combustion of
1 m of gas
3
21.6
21.6
21.6
51
25
57.5
57.5
)
3
