| INSTALLING THE TURNTABLE

PLATTER
1
Remove the cap from the center of the
turntable.
2
Insert the ball bearing into the bearing
housing of the turntable taking care to
centre it on the bottom seat.
3
Add oil to the spindle as shown below.
1
drop
Ball bearing
4
Insert the spindle into the bearing
housing.*
5
Screw the lifting eye bolt in the platter to
lift it.
6
Position the platter on the spindle.
* PLEASE NOTE: the bearing housing is already
installed in the plinth of the turntable.
Do not remove it.
4
EN
DE
IT
FR
Lifting eye
bolt
Platter
Platter
spindle
Bearing
housing
