Selected Condition of Auto Scan, Manual Scan, or Test

Users should first select AUTO SCAN (
characteristics of a solar panel.
1. Press
Kelvin clips to the solar panel and the Analyzer. The red Kelvin clip is for
positive pole and the black Kelvin clip for negative pole.
2. Press
the result will come out like below.
Afterward, if users are interested in a specific operating range, they can enter
the beginning and ending values of scan in the setup menu.
Press SCAN (
1. Press
Kelvin clips to the solar panel and the Analyzer. The red Kelvin clip is for
positive pole and the black Kelvin clip for negative pole.
2. Press
for scanning)
Current Range of Scan begin: 200mA
Current Range of Scan end: 548mA
After setting up the current range, press
SETUP menu.
Note: If the "Current Range of Scan begin" is over "Ishort", then the
scanning will not be performed and no result will come out.
button to turn on the Analyzer. Properly connect the pair of
button to start AUTO SCAN. After the scanning is finished,
) button to test the specific range.
button to turn on the Analyzer. Properly connect the pair of
button to enter the SETUP menu: (Type in the current range
) to obtain a general idea of
button again to exit the
