Original instructions Tiger 20-30 kW ..9 ..11 ..13 ..15 ..17 ..19 ..21 ..23 ..25 ..27 ..29 This product is only suitable for well insulated spaces or occasional use. Denna produkt är endast lämpad för välisolerade utrymmen eller sporadisk användning. Dette produktet er bare egnet for velisolerte rom eller sporadisk bruk.
Seite 2
Tiger 20-30 kW °C [mm] [mm] [mm] Resetting the overheat protection Fig. 1 SE: Återställning överhettningsskydd NO: Tilbakestille overopphetingsvernet DE: Zurücksetzen des Überhitzungsschutzes RU: Перезапуск защиты от перегрева FR: Réinitialisation de la protection anti-surchauffe ES: Reajustar la protección contra el sobrecalentamiento NL: Resetten van de oververhittingsbeveiliging PL: Resetowanie zabezpieczenia przed przegrzaniem FI: Ylikuumenemissuojan palauttaminen...
Seite 3
Tiger 20-30 kW Tiger 20 kW 400V3~ 400V3~ TIG203-0 TIG203-0 TIG203-0AU 230V 400V High speed Low speed 277246 Type Cable IEC60309 TIG203-0 271754 4G6x1,8m CP 432-6 271758 TIG303-0 4G10x1,8m Tiger 30 kW 400V3~ 281180 TIG203-0AU 4G6x4m CP 432-6 400V3~ TIG303-0 TIG303-0 X X X 230V...
Seite 4
Tiger 20-30 kW Tiger 20 kW 400V3N~ 400V3N~ TIG203 TIG203 277366 Type Cable IEC60309 TIG203 271756 5G6x1,8m CP 432-6 TIG303 271759 5G10x1,8m Tiger 30 kW 400V3N~ 400V3N~ TIG303 TIG303 X X X 277365...
Seite 5
Tiger 20-30 kW Tiger 20 kW 230V3~ 230V3~ TIG2023 TIG2023 277259 Type Cable TIG2023 271757 4G10x1,8m 230V3~ Tiger 30 kW 230V3~ TIG3023 271762 4G16x1,8m TIG3023 TIG3023 X X X 277279...
Seite 6
Tiger 20-30 kW Tiger 30 kW 440V3~ / 500V3~ 500V/440V3~ TIG305 TIG305 440V3~ 440V 500V 440V 500V 230V 230V X X X 277249 Type Cable TIG305 271763 4G6x1,8m...
Seite 7
Tiger 20-30 kW Tiger 20-30 (IP44) Item no Type Output Airflow Sound Sound ∆ Motor Voltage Amp. Weight steps power pressure [kW] [m³/h] [dB(A)] [dB(A)] [°C] [kg] 271754 TIG203-0 0/10/20 1950/2400 54/61 31/26 106 400V3~ 271756 TIG203 0/10/20 1940 400V3N~ 271757 TIG2023 0/10/20...
Seite 8
Tiger 20-30 kW ) Mesures de la puissance acoustique (L ) selon la norme ISO 27327-2 : 2014, Installation de type E. ) Pression acoustique (L ). Conditions : Distance de l’appareil : 3 mètres. Facteur directionnel : 2. Surface d’absorption : 200 m².
Seite 9
Tiger 20-30 kW Installation and operating instructions General Instructions Read these instructions carefully prior to TIG203, TIG303, TIG305 installation and use. Keep this manual for future reference. Built-in thermostat with setting range °C The product may only be used as set out in 5–35°C.
Tiger 20-30 kW CAUTION — Some parts of this product can from the element. The drying time can vary become very hot and cause burns. Particular from a few hours to a few days. As a preventive attention has to be given where children and measure, the unit should occasionally be run for a short time when it is not being used for vulnerable people are present.
