CLASSIFICATION
7. TECHNICAL SPECIFICATIONS
SUBJECT
1. GENERAL SECTION
PRODUCT
POWER SOURCE
POWER CONSUMPTION
DIMENSIONS
WEIGHT
2. STANDARD TEST CONDITION:
Ambient Temperature
Relative Humidity
NOTE: Measurements can be carried out between 5 degC to 35 degC and 45% to 85% relative humidity.
3. AUDIO CHARACTERISTICS (Unbalance Output Load = 100K ohm, Balance Output Load = 600 ohm,
{Signal to Signal 600 OHM}, Phones = 33 ohm, EQ/Filter Flat , Fader At Max. Unless Otherwise Noted)
4. INPUT/OUTPUT IMPEDANCE & SENSITIVITY: (1KHz INPUT , MIC/AUX, TRIM, MASTER AT MAX)
4-1. INPUT IMPEDANCE AND REFERENCE INPUT LEVEL:
LINE/CD：
PHONO：
AUX：
MIC1/2：
4-2. OUTPUT IMPEDANCE AND REFERENCE OUT LEVEL:
MASTER：
BALANCED：
BOOTH：
RECORD：
PHONES：
5. MAXIMUM OUTPUT: (1KHz, INPUT, GAIN AT MAX, MASTER/BOOTH/CUE AT 12 O'CLOCK, WITH
A-w/20kHz LPF, OUTPUT LEVEL LESS THAN 1%)
MASTER UNBALANCED： MORE THAN +17.8 dBV(7.762 V) MORE THAN +16 dBV (6.31 V)
MASTER BALANCED：
BOOTH BALANCE：
PHONE：
42

GENERAL SPECIFICATION

45K OHM /0 dBV(1V)
47K OHM /-35 dBV(3.16 mV)
45K OHM /0 dBV(200 mV)
5K OHM /-42 dBV(1.99 mV) (Unbalance)
1K OHM /-2.2 dBV (776 mV)
600 OHM /-2.2 dBV (776 mV)
600 OHM /-2.2 dBV (776 mV)
1K OHM /-11 dBV (281.8 mV)
33 OHM /-13 dBV (223.9 mV)
Nominal
MORE THAN +17.8 dBV(7.762 V) MORE THAN +16 dBV (6.31 V)
MORE THAN +17.8 dBV(7.762 V) MORE THAN +16 dBV (6.31 V)
MORE THAN +6.8 dBV(2.188 V)
HANPIN ELECTRON(SHENZHEN) CO., LTD.
FENGHUANG INDUSTRIALDISTRICT,FU YONG TOWN, SHEN ZHENCITY, GUANG DONG ,CHINA
DIGITAL CLUB MIXER WITH DVS-INTERFACE
AC100 - 240V, 50/60Hz
23WATTS
322mm (W) X 387mm (D) X 107.5mm (H)
6.9kg
23 +/- 2 degC
65% +/- 5%
1-1
PAGE
DATE
Nominal Limited
± 1dB ± 2dB
± 1dB ± 2dB
± 1dB ± 2dB
± 1dB ± 2dB
± 1dB ± 2dB
Limited
MORE THAN +5 dBV (1.778 V)
APPROVAL CHECK
(V0.13, 121416)
DESIGN
