Contents
Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 21
Function and features . . . . . . . . . . . . . . . . . . . . . . . . . page 22
Setting of the system . . . . . . . . . . . . . . . . . . . . . . . . . page 23
Compressed air supply . . . . . . . . . . . . . . . . . . . . . . . . page 24
Installation of the control unit . . . . . . . . . . . . . . . . . . . page 24
Preparations for set-up and installation . . . . . . . . . . . . page 26
Setting (adjustment of the pneumatic bridge) . . . . . . . page 27
Technical information (pressure sensor) . . . . . . . . . . . . .page 29
Technical information (pneumatic system) . . . . . . . . . . page 33
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 36
Scale drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 37
Page 20
All manuals and user guides at all-guides.com
Please read the product description prior to installing the unit.
Please check that the product is suitable for your application
without any restrictions.
If the operating instructions or the technical data are not
adhered to, personal injury and/or damage to property may
occur.
Please check in all applications that the product materials (see
Technical data) are compatible with the media to be mea-
sured.
System pressure:
0.7 up to max. 1.5 bar (for optimum operation 1 bar).
Set the pressure regulator to a pressure < 1.5 bar (150 kPa / 22 PSI)
before you install the control unit.
Recommended quality class of the air supply (to DIN ISO 8573-1):
class 2

Safety instructions
