3 - SPECIFICATIONS
3.8 Motorcompressor parts
POS. DESCRIPTION
1 Nameplate
2 Accelerator lever
3 Handle
4 Lever
5 Starter
6 Engine accelerator lever
7 Pneumatic self-regulating Regulates the engine (10) r.p.m. automatically
cylinder
8 Fuel tank cock
9 Engine pull-cord starter
10 Engine
11 Muffler
12 Engine air filter
13 Net guard
14 Filler
15 Oil plug
16 ON/OFF switch
17 Compressor tank
18 Pilot valve
19 Tank
20 Hose reel support
21 Compressor air filter
22 Compressor head block
23 Fittings and couplings
24 Oil drops regulator
25 Pressure regulator
26 Operating air pressure
gauge
27 Lubricator
28 Exhaust valve
29 Air filter
30 Oil filler
31 Sight glass
32 Oil plug
33 Hydraulic hose
34 Tank pressure gauge
35 Exhaust valve
36 Safety valve
37 Pulley
38 Drive belt
39 Transmission belt
40 Belt drive pulley
41 Stretching lever
42 Pulley
43 Oil dipstick (diesel)
44 Switch lever (diesel)
- Protective clothing
- Working position
FUNCTION
CE nameplate with compressor identification details
Controlled by the operator, it regulates the engine r.p.m. when the
motorcompressor moves forward
Allow the user to move the compressor
Automatic two-wheel drive, controlled by the operator
It is operated before the machine is started up
Regulates the engine revolutions
Used to shut off the fuel supply
Cord to be tugged to start the engine
Operates the compressor through a belt drive
Engine exhaust pipe
Filters the inflowing air to cool the engine
Protects the operator from the moving parts
Used to add oil to the engine
Drains the oil from the engine
Turn the switch to the ON position to start the engine, turn it to the
OFF position to stop the engine
Accumulates air pressure for operating the tools
Keeps the pressure in the air tank at the correct level
Contains the fuel required to operate the engine
The hose reel is connected to the compressor with a support
Filters the inflowing air to cool the compressor
Fills the tank with compressed air
Connect the pneumatic tools
Regulates the oil flow to the lubricator
Regulates the pressure of the outflowing air
Indicates the pressure of the outflowing air
Used to spray oil into the outflowing air so as to lubricate all
pneumatic tools
Used to exhaust compressed air
Retains all impurities contained in the outflowing air
Used to add or change oil in the compressor
Indicates the oil level in the compressor
Used to drain the oil from the compressor
Air hose connecting the compressor head block with the air tank
Indicates the pressure in the air tank
Used to exhaust the air from the tank
Comes into action when the pilot valve is faulty
Transmits motion to the compressor engine
Transmits motion from the engine to the compressor
Drive belt for moving the motorcompressor forward
Keeps the correct belt position
Transmits forward motion to the wheels
Transmits forward motion to the wheels
Allows to check the engine oil level
Stops the engine
The picture shows the clothing the operator has to wear
Indicates the right motorcompressor working position
REFERENCE
A
B
B
B
C
C
C
C
C
C
D
D
D
D
D
E
E
E
G
G
G
G
H
H
H
H
H
H
H
I
I
I
I
L
L
L
M
M
N
N
N
N
O
P
A
F
