INSTALLATION
Mounting
GB 14
• Position the bracket (E) for attaching the exhaust duct (C) on the
vertical line, 65 mm below the marked maximum height of the
exhaust duct (C). Mark the positions of the mounting holes for the
bracket (E), drill the holes, position the plugs and screw the bracket
(E) to the wall.
• If necessary, install the air deflector (D) for recirculation use.
• Connect the cooker hood to the mains.
• Position the exhaust duct (B+C) on the cooker hood and screw it to
the upper bracket (E) with the corresponding screws.
