Once the particular mounting (4i) is screwed into the wall, insert the ceramic heat exchanger (7)
with the relative filters (8), positioning it in the middle of the recessed tube (6), as in the image
below:
Fix the main unit (3) - together with the shutter components (2) and the esthetic front cover(1),
already mounted upon it - snap-lock onto the specific wall mounting (4i), until it is attached with all
teeth.Make sure to have installed the main unit onto the wall, by turning on the switches on the
left.

MAINTENANCE

All the device maintenance operations are intended solely and exclusively to qualified personnel.
Make sure that the network connection in the place of installation is disconnected before the
maintenance operations.
