GLOSSARY

Characteristic Angles
This term refers to all the angles that can be normally
measured on a wheel aligner (total front/rear toe,
left/right and front/rear half toe values, left/right
and front/rear camber, left/right caster, left/right
king-pin angle, and steering angle difference at 20°).
Equatorial plane
Ideal vertical plane that divides the wheel into
two equal parts.
Rotating platform
Base equipped with a disk on which the steered
wheels of a vehicle rest; it is used to reduce friction
between the wheel and the ground, in order to
favour the settling of the suspensions and cancel
the measuring errors during the steering.
It is highly important to keep the area between
the disk and the base clean at all times.
Oscillating footboard
The function is similar to that of the rotating plat-
form, but it is used for the non-steered wheels only.
Infrared rays (IR)
Electromagnetic waves that are invisible to the
naked eye.
Target
Measurement instruments that are applied to the
vehicle wheels to measure characteristic angles.
Clamp
Adapter between the wheel and the measuring
target.
98
FINAL COMMUNICATION
TO THE USER
Dear user, we from Corghi SpA always do our
utmost to supply you with a product that is cut-
ting edge, qualitatively superior but above all
that gives you the greatest professional satisfac-
tion possible.
We from Corghi SpA try - for our products - to
reach the state of the art not only in terms of
design but also as far as the documentation in
concerned. This is why, if you feel that there are
inaccuracies or inconsistencies in this document
we would be very grateful if you would let us
know by contacting the Corghi SpA Technical
Assistance Service anyway you prefer (phone,
email), or even leave us a written communication
on our portal (www.corghi.com)!
Operator's manual R.E.M.O. COMPACT
