Device Layout

Front (Green)
Rear (Black)
Center/Sub (Orange)
Side (Gray)
1. Headset
2. Detachable microphone boom
3. Five pairs of neodymium magnet
speakers
4. HDMI headset port
5. USB port
6. HDMI speaker port
7. E NC (Environmental Noise
Cancellation) microphone
8. M ode on/off switch and Mode
parameter control*
NOTE: Refer to the table in section Using the Strix 7.1 Control Box for the functions of the
Mode Selector and Mode On/Off Switch & Mode Parameter Control
ASUS Strix 7.1
manuals search engine
9. 7.1-channel / stereo switching button
10. Headphone amplifier on/off
11. Mode selector*
12. Quick microphone mute/unmute
13. H eadset/speaker switching button
14. E NC (Environmental Noise
Cancellation) on/off switch
15. HDMI speaker cable
16. U SB Y-cable
3
