P/N 4-1579002-2

2.3 Information on the Content of the Operator Manual

The present operator manual describes the use and operation of the stripping hand tool P/N 4-1579002-2
and the necessary service work.
For more information and technical support contact:
Customer Services
Ampèrestraße 12-14
D-64625 Bensheim
3
The stripping hand tool is designed to strip TE Connectivity Solar wires. The stripping hand tool allows for
high quality, damage-free stripping of 2.5 / 4.0 / 6.0 mm² Solar wires. For TE Connectivity approved wires
see processing specification 114-94061-1, -2.
NOTE
All dimensions in this operator manual are given in millimeters "mm". The components illustrated are not
drawn to scale.
APPLICATION NOTE
Cumulative Trauma Disorders can result from prolonged use of hand tools. Hand tools are intended for
occasional use and low volume applications. For extended use or production operations TE Connectivity
offers a wide selection of appropriate tools.
NOTE
The stripping hand tool should only be used for the purpose described herein.
SAFETY NOTICE
► Do not reach into the blade area (see Figure 1) Risk of injury!
► Remove any stripping remains with a tool such as a small screwdriver.
Downloaded from www.Manualslib.com

Intended Use

manuals search engine
Figure 1
Page 12 / 16
411-18508 Rev C
