Preparing Built-in Camera

(This feature is not available for all models.)
1 Pull up the slide at the back of the TV.
Angle Adjustment Lever
NOTE
Remove the protective film before using the built-
in camera.
2 You can adjust the angle of the camera with the
angle adjustment lever on the back of the built-in
camera.
<Side View>
(Only 65/79/84UB98)
7°
5°
Lever Lens
(Only 98UB98)
3°
5°
Lever Lens
3 Push down the built-in camera when you are not
using it.
Slide

Name of Parts of Built-in Camera

Microphone

Checking the Camera's Shooting Range

1 Press the
menu.
2 Select
button.
5°
7°
The optimal distance from the camera to use the
motion recognition function is between 1.5 m and
4.5 m.
5°
3°
ASSEMBLING AND PREPARING
Protective Film
Microphone
Camera Lens
(Home) button to access the Home
Camera and then press the
NOTE
25
Wheel(OK)
