Shelf, Mini, Piccolo

Positioning

Your speakers are set up correctly, if
your favourite listening position and
the speakers form an approximately
equilateral triangle. The speakers
should radiate from an acoustically
hard environment
reverberation characteristics into the
more damped part of the listening
area.
No objects should be placed in front
of or too near to the speakers. The
listener should be able to see both
speakers completely.
Please make sure that you do not
put things too close to the rear side
of the loudspeaker, since part of the
sound comes out of the bass tubes
on the rear of your speakers.
Therefore, we recommend you to
leave about one inch of space
behind it.
For best sound quality, position the
speakers at ear level (± 12 in. / ± 30
cm).
The low frequency behaviour may
be controlled by the distance of the
speakers to the walls. Depending on
the acoustic actualities of your
room, very serious changes of the
bass volume can occur between the
possibilities "larger distance" (slim
bass) and "in the angle of the room"
(beefy bass)''.

Wall-mount with ball joint brackets

Revox provides ball joint wall
brackets with a wide swivelling
range. The brackets are designed
for screw(s) wall-mounting and
attach to the speakers by means of
with good three
information on wall-mounting, refer
to the instructions that come with
the wall brackets.
Ball joint wall bracket:
Piccolo, Mini: 1.084.434.00
Shelf
11
screws. For detailed
1.084.606.00
