Quick Start
Thank you for purchasing the MSI
Z270-A PRO
motherboard. This
®
Quick Start section provides demonstration diagrams about how to
install your computer. Some of the installations also provide video
demonstrations. Please link to the URL to watch it with the web
browser on your phone or tablet. You may have even link to the URL
by scanning the QR code.
Kurzanleitung
Danke, dass Sie das MSI
Z270-A PRO
Motherboard gewählt
®
haben. Dieser Abschnitt der Kurzanleitung bietet eine Demo zur
Installation Ihres Computers. Manche Installationen bieten auch
die Videodemonstrationen. Klicken Sie auf die URL, um diese
Videoanleitung mit Ihrem Browser auf Ihrem Handy oder Table
anzusehen. Oder scannen Sie auch den QR Code mit Ihrem Handy,
um die URL zu öffnen.
Présentation rapide
Merci d' avoir choisi la carte mère MSI
Z270-A
PRO. Ce manuel
®
fournit une rapide présentation avec des illustrations explicatives
qui vous aideront à assembler votre ordinateur. Des tutoriels vidéo
sont disponibles pour certaines étapes. Cliquez sur le lien fourni
pour regarder la vidéo sur votre téléphone ou votre tablette. Vous
pouvez également accéder au lien en scannant le QR code qui lui est
associé.
Быстрый старт
Благодарим вас за покупку материнской платы MSI
Z270-A
®
PRO. В этом разделе представлена информация, которая
поможет вам при сборке комьютера. Для некоторых
этапов сборки имеются видеоинструкции. Для просмотра
видео, необходимо открыть соответствующую ссылку в
веб-браузере на вашем телефоне или планшете. Вы также
можете выполнить переход по ссылке, путем сканирования
QR-кода.
I
Quick Start

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für MSI Z270-A PRO

  • Seite 1 Videoanleitung mit Ihrem Browser auf Ihrem Handy oder Table anzusehen. Oder scannen Sie auch den QR Code mit Ihrem Handy, um die URL zu öffnen. Présentation rapide Merci d’ avoir choisi la carte mère MSI Z270-A PRO. Ce manuel ®...
  • Seite 2 Installing a Processor/ Installation des Prozessors/ Installer un processeur/ Установка процессора http://youtu.be/bf5La099urI Quick Start...
  • Seite 3 Installing DDR4 memory/ Installation des DDR4-Speichers/ Installer une mémoire DDR4/ Установка памяти DDR4 http://youtu.be/T03aDrJPyQs DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Quick Start...
  • Seite 4 Connecting the Front Panel Header/ Anschließen der Frontpanel-Stiftleiste/ Connecter un connecteur du panneau avant/ Подключение разъемов передней панели http://youtu.be/DPELIdVNZUI HDD LED + Power LED + HDD LED - Power LED - Reset Switch Power Switch Reset Switch Power Switch JFP1 Reserved No Pin JFP1...
  • Seite 5 Installing the Motherboard/ Installation des Motherboards/ Installer la carte mère/ Установка материнской платы Quick Start...
  • Seite 6 Installing SATA Drives/ Installation der SATA-Laufwerke/ Installer le disque dur SATA/ Установка дисков SATA http://youtu.be/RZsMpqxythc Quick Start...
  • Seite 7 Installing a Graphics Card/ Einbau der Grafikkarte/ Installer une carte graphique/ Установка дискретной видеокарты http://youtu.be/mG0GZpr9w_A Quick Start...
  • Seite 8 Connecting Peripheral Devices/ Peripheriegeräte/ Connecter un périphérique anschliessen/ Подключение периферийных устройств VIII Quick Start...
  • Seite 9 Connecting the Power Connectors/ Stromanschlüsse anschliessen/ Connecter les câbles du module d’ alimentation/ Подключение разъемов питания http://youtu.be/gkDYyR_83I4 ATX_PWR1 CPU_PWR1 Quick Start...
  • Seite 10: Power On/ Einschalten/ Mettre Sous-Tension/ Включение Питания

    Power On/ Einschalten/ Mettre sous-tension/ Включение питания Quick Start...
  • Seite 11: Inhaltsverzeichnis

    Contents Safety Information ....................2 Specifications ......................3 Rear I/O Panel ....................... 7 LAN Port LED Status Table..................7 Audio Ports Configuration ..................7 Realtek HD Audio Manager ..................8 Overview of Components ..................10 CPU Socket ......................11 DIMM Slots ......................12 PCI_E1~6: PCIe Expansion Slots ................
  • Seite 12: Safety Information

    Safety Information The components included in this package are prone to damage from electrostatic discharge (ESD). Please adhere to the following instructions to ensure successful computer assembly. Ensure that all components are securely connected. Loose connections may cause the computer to not recognize a component or fail to start. Hold the motherboard by the edges to avoid touching sensitive components.
  • Seite 13: Specifications

    Optane™ Technology is only supported when using 7th Gen processors. ® Before using Intel Optane™ memory modules, please ensure that you have ® updated the drivers and BIOS to the latest version from MSI website. Intel Z270 Chipset ® RAID...
  • Seite 14 Continued from previous page Intel Z270 Chipset ® 8x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ƒ ports on the back panel, 4 ports available through the internal USB connectors) 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on ƒ...
  • Seite 15 UEFI AMI BIOS BIOS Features ACPI 5.0, PnP 1.0a, SM BIOS 2.8 Multi-language Drivers SUPER CHARGER FAST BOOT COMMAND CENTER LIVE UPDATE 6 MSI SMART TOOL Software X-BOOST MYSTIC LIGHT RAMDISK NETWORK MANAGER CPU-Z MSI GAMING Intel Extreme Tuning Utility ®...
  • Seite 16 Intel Optane Memory Ready ® Turbo M.2 M.2 Genie Pump Fan Smart Fan Control PCI-E Steel Armor MSI Special Features Muitl GPU - CrossFire Technology DDR4 Boost OC Genie 4 X-Boost Military Class 5 7000+ Quality Test RAMDisk Click BIOS 5...
  • Seite 17: Rear I/O Panel

    Rear I/O Panel Audio Ports PS/2 Port USB 3.1 Gen1 DisplayPort USB 2.0 DVI-D USB 3.1 Gen1 LAN Port LED Status Table Link/ Activity LED Speed LED Status Description Status Description No link 10 Mbps connection Yellow Linked Green 100 Mbps connection Blinking Data activity Orange...
  • Seite 18: Realtek Hd Audio Manager

    Realtek HD Audio Manager After installing the Realtek HD Audio driver, the Realtek HD Audio Manager icon will appear in the system tray. Double click on the icon to launch. Device Selection Advanced Settings Jack Status Application Enhancement Main Volume Connector Strings Profiles...
  • Seite 19 Audio jacks to headphone and microphone diagram Audio jacks to stereo speakers diagram AUDIO INPUT Audio jacks to 7.1-channel speakers diagram AUDIO INPUT Front Center/ Subwoofer Side Rear Rear I/O Panel...
  • Seite 20: Overview Of Components

    Overview of Components DIMMA1 SYS_FAN4 DIMMA2 CPU_FAN1 CPU_PWR1 DIMMB1 DIMMB2 CPU Socket PUMP_FAN1 SYS_FAN2 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA2 PCI_E3 SATA1 PCI_E4 JTBT1* SATA▼3▲4 PCI_E5 SATA▼5▲6 JTPM1 PCI_E6 JCI1 JFP1 JFP2 JAUD1 SYS_FAN1 SYS_FAN3 JUSB1 JCOM1 JUSB2...
  • Seite 21: Cpu Socket

    Always unplug the power cord from the power outlet before installing or removing the CPU. Please retain the CPU protective cap after installing the processor. MSI will deal with Return Merchandise Authorization (RMA) requests if only the motherboard comes with the protective cap on the CPU socket.
  • Seite 22: Dimm Slots

    DIMM Slots DIMMA1 DIMMB1 Channel A Channel B DIMMA2 DIMMB2 Memory module installation recommendation DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Important Always insert memory modules in the DIMMA2 slot first. Due to chipset resource usage, the available capacity of memory will be a little less than the amount of installed.
  • Seite 23: Pci_E1~6: Pcie Expansion Slots

    If you install a large and heavy graphics card, you need to use a tool such as MSI Gaming Series Graphics Card Bolster to support its weight and to prevent deformation of the slot. Overview of Components...
  • Seite 24: M2_1: M.2 Slot (Key M)

    M2_1: M.2 Slot (Key M) Important Intel RST only supports PCIe M.2 SSD with UEFI ROM. ® Intel Optane Memory Ready. ® Video Demonstration Watch the video to learn how to Install M.2 module. http://youtu.be/JCTFABytrYA Installing M.2 module Remove the screw from the base screw.
  • Seite 25: Sata1~6: Sata 6Gb/S Connectors

    SATA1~6: SATA 6Gb/s Connectors These connectors are SATA 6Gb/s interface ports. Each connector can connect to one SATA device. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Important The SATA1 port will be unavailable when an M.2 SATA SSD module has been installed in the M.2 slot.
  • Seite 26: Cpu_Pwr1, Atx_Pwr1: Power Connectors

    CPU_PWR1, ATX_PWR1: Power Connectors These connectors allow you to connect an ATX power supply. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground...
  • Seite 27: Jusb1~2: Usb 2.0 Connectors

    JUSB1~2: USB 2.0 Connectors These connectors allow you to connect USB 2.0 ports on the front panel. USB0- USB1- USB0+ USB1+ Ground Ground No Pin Important Note that the VCC and Ground pins must be connected correctly to avoid possible damage.
  • Seite 28: Cpu_Fan1,Sys_Fan1~4, Pump_Fan1: Fan Connectors

    CPU_FAN1,SYS_FAN1~4, PUMP_FAN1: Fan Connectors Fan connectors can be classified as PWM (Pulse Width Modulation) Mode or DC Mode. PWM Mode fan connectors provide constant 12V output and adjust fan speed with speed control signal. DC Mode fan connectors control fan speed by changing voltage. When you plug a 3-pin (Non-PWM) fan to a fan connector in PWM mode, the fan speed will always maintain at 100%, which might create a lot of noise.
  • Seite 29: Jaud1: Front Audio Connector

    JAUD1: Front Audio Connector This connector allows you to connect audio jacks on the front panel. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Chassis Intrusion Connector This connector allows you to connect the chassis intrusion switch cable. Normal Trigger the chassis intrusion event...
  • Seite 30: Jtpm1: Tpm Module Connector

    JTPM1: TPM Module Connector This connector is for TPM (Trusted Platform Module). Please refer to the TPM security platform manual for more details and usages. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address &...
  • Seite 31: Jlpt1: Parallel Port Connector

    JLPT1: Parallel Port Connector This connector allows you to connect the optional parallel port with bracket. RSTB# AFD# PRND0 ERR# PRND1 PINIT# PRND2 LPT_SLIN# PRND3 Ground PRND4 Ground PRND5 Ground PRND6 Ground PRND7 Ground ACK# Ground BUSY Ground Ground SLCT No Pin EZ Debug LED These LEDs indicate the status of key components during booting process.
  • Seite 32: Bios Setup

    Press Delete key, when the Press DEL key to enter Setup Menu, F11 to enter Boot Menu message appears on the screen during the boot process. Use MSI FAST BOOT application. Click on GO2BIOS button and choose OK. The system will reboot and enter BIOS setup directly.
  • Seite 33: Resetting Bios

    Updating BIOS Updating BIOS with M-FLASH Before updating: Please download the latest BIOS file that matches your motherboard model from MSI website. And then save the BIOS file into the USB flash drive. Updating BIOS: Press Del key to enter the BIOS Setup during POST.
  • Seite 34: Ez Mode

    EZ Mode At EZ mode, it provides the basic system information and allows you to configure the basic setting. To configure the advanced BIOS settings, please enter the Advanced Mode by pressing the Setup Mode switch or F7 function key. Screenshot Setup Mode switch XMP switch...
  • Seite 35 Boot device priority bar - you can move the device icons to change the boot priority. The boot priority from high to low is left to right. Information display - click on the CPU, Memory, Storage, Fan Info and Help buttons on left side to display related information.
  • Seite 36: Advanced Mode

    Advanced Mode Press Setup Mode switch or F7 function key can switch between EZ Mode and Advanced Mode in BIOS setup. Screenshot XMP switch Setup Mode switch Search Language System information OC GENIE 4 switch Boot device priority bar BIOS menu BIOS menu selection selection...
  • Seite 37: Oc Menu

    OC Menu This menu is for advanced users who want to overclock the motherboard. Important Overclocking your PC manually is only recommended for advanced users. Overclocking is not guaranteed, and if done improperly, it could void your warranty or severely damage your hardware. If you are unfamiliar with overclocking, we advise you to use OC GENIE 4 function for easy overclocking.
  • Seite 38 CPU Ratio Mode [Dynamic Mode]* Selects the CPU Ratio operating mode. This item will appear when you set the CPU ratio manually. [Fixed Mode] Fixes the CPU ratio. [Dynamic Mode] CPU ratio will be changed dynamically according to the CPU loading.
  • Seite 39 CPU Base Clock Apply Mode [Auto]* Sets the applying mode for adjusted CPU base clock. [Auto] This setting will be configured automatically by BIOS. [Next Boot] CPU will run the adjusted CPU base clock at next boot. [Immediate] CPU runs the adjusted CPU base clock immediately. [During Boot] CPU will run the adjusted CPU base clock during boot.
  • Seite 40 fCPU GT Loadline Calibration Control [Auto] The voltage of the GPU embeeded in CPU will decrease proportionally according to GPU loading. Higher load-line calibration could get higher voltage and good overclocking performance, but increase the temperature of the CPU and VRM. CPU Core/ GT Voltage Mode [Auto]* Selects the control mode for CPU Core/ GT voltages.
  • Seite 41 CPU Features Press Enter to enter the sub-menu. fHyper-Threading [Enabled] Intel Hyper-Threading technology treats the multi cores inside the processor as multi logical processors that can execute instructions simultaneously. In this way, the system performance is highly improved. This item appears when the installed CPU supports this technology.
  • Seite 42 fIntel Adaptive Thermal Monitor [Enabled] Enables or disables the Intel adaptive thermal monitor function to protect the CPU from overheating. [Enabled] Throttles down the CPU core clock speed when the CPU is over the adaptive temperature. [Disabled] Disables this function. fIntel C-State [Auto] Enables or disables the Intel C-state.
  • Seite 43 fLong Duration Power Limit (W) [Auto] Sets the long duration TDP power limit for CPU in Turbo Boost mode. fLong Duration Maintained (s) [Auto] Sets the maintaining time for Long duration power Limit(W). fShort Duration Power Limit (W) [Auto] Sets the short duration TDP power limit for CPU in Turbo Boost mode. fCPU Current Limit (A) [Auto] Sets maximum current limit of CPU package in Turbo Boost mode.
  • Seite 44: Software Description

    7/ 8.1/ 10 disc into your optical drive. ® Note: Due to chipset limitation, during the Windows 7 installation process, USB optical drives or USB flash drives are not supported. You can use MSI Smart Tool to install Windows ®...
  • Seite 45 Inhalt Sicherheitshinweis ....................2 Spezifikationen ...................... 3 Rückseite E/A ......................7 LAN Port LED Zustandstabelle ................7 Konfiguration der Audioanschlüsse ............... 7 Realtek HD Audio Manager ..................8 Übersicht der Komponenten ................10 CPU Sockel ......................11 DIMM-Steckplätze ....................12 PCI_E1~6: PCIe Erweiterungssteckplätze ............
  • Seite 46: Sicherheitshinweis

    Sicherheitshinweis Die im Paket enthaltene Komponenten sind der Beschädigung durch elektrostatischen Entladung (ESD). Beachten Sie bitte die folgenden Hinweise, um die erfolgreichen Computermontage sicherzustellen. Stellen Sie sicher, dass alle Komponenten fest angeschlossen sind. Lockere Steckverbindungen können Probleme verursachen, zum Beispiel: Der Computer erkennt eine Komponente nicht oder startet nicht.
  • Seite 47: Spezifikationen

    2400(OC)/ 2133 MHz* Dual-Kanal-Speicherarchitektur Unterstützt Intel Extreme Memory Profile (XMP) ® *Weitere Informationen zu kompatiblen Speicher finden Sie unter: http://www.msi.com. 2x PCIe 3.0 x16-Steckplätze (unterstützt x16/x4 Modus) Erweiterung- anschlüsse 4x PCIe 3.0 x1-Steckplätze 1x VGA Anschluss, Unterstützung einer maximalen Auflösung von 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz 1x DVI-D Anschluss, Unterstützung einer maximalen...
  • Seite 48 ™ der 7. Generation unterstützt. Bevor Sie Intel Optane Speichermodule ® ™ verwenden, stellen Sie bitte über downloads von der MSI Website sicher, dass die Treiber und das BIOS auf dem neuesten Stand sind. Intel Z270 Chipsatz ® RAID Unterstützt RAID 0, RAID 1, RAID 5 und RAID 10 für SATA Speichergeräte...
  • Seite 49 Fortsetzung der vorherigen Seite 24-poliger ATX Stromanschluss x1 8-poliger ATX12V Stromanschluss x1 SATA 6Gb/s Anschlüsse x6 USB 3.1 Gen1 Anschlüsse x2 (unterstützt zusätzliche 4 USB 3.1 Gen1-Ports) USB 2.0 Anschlüsse x2 (unterstützt zusätzliche 4 USB 2.0-Ports) 4-poliger CPU-Lüfter-Anschluss x1 4-poliger Anschluss für die Wasserpumpe x1 Interne Anschlüsse 4-polige System-Lüfter-Anschlüsse x4 Audioanschluss des Frontpanels x1...
  • Seite 50 Fortsetzung der vorherigen Seite Treiber SUPER CHARGER FAST BOOT COMMAND CENTER LIVE UPDATE 6 MSI SMART TOOL Software X-BOOST MYSTIC LIGHT RAMDISK NETWORK MANAGER CPU-Z MSI GAMING Intel Extreme Tuning Utility ® Norton Internet Security Solution ™ Google Chrome , Google Toolbar, Google Drive ™...
  • Seite 51: Rückseite E/A

    Rückseite E/A Audioanschlüsse PS/2 Anschluss USB 3.1 Gen1 DisplayPort USB 2.0 DVI-D USB 3.1 Gen1 LAN Port LED Zustandstabelle Verbindung/ Aktivität LED Geschwindigkeit LED Zustand Bezeichnung Zustand Bezeichnung Keine Verbindung 10 Mbps-Verbindung Gelb Verbindung Grün 100 Mbps-Verbindung Blinkt Datenaktivität Orange 1 Gbps-Verbindung Konfiguration der Audioanschlüsse Kanal...
  • Seite 52: Realtek Hd Audio Manager

    Realtek HD Audio Manager Nach der Installation des Realtek HD Audio-Treibers, wird das Symbol Realtek HD Audio Manager in der Taskleiste angezeigt. Klicken Sie doppelt auf dieses Symbol, um das Programm zu starten. Geräteauswahl Erweiterte Einstellungen Verbindungs- status Optimierungen Lautstärke Anschlüsse Profil Geräteauswahl - Ermöglicht die Auswahl der Audio-Ausgangs Quelle.
  • Seite 53: Audiobuchsen Für Stereo-Lautsprecher

    Audiobuchsen für den Anschluss von einem Kopfhörer und Mikrofon Audiobuchsen für Stereo-Lautsprecher AUDIO INPUT Audiobuchsen für 7.1 Kanal Anlage AUDIO INPUT Front Center/ Subwoofer Side Rear Rückseite E/A...
  • Seite 54: Übersicht Der Komponenten

    Übersicht der Komponenten DIMMA1 SYS_FAN4 DIMMA2 CPU_FAN1 CPU_PWR1 DIMMB1 DIMMB2 CPU Sockel PUMP_FAN1 SYS_FAN2 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA2 PCI_E3 SATA1 PCI_E4 JTBT1* SATA▼3▲4 PCI_E5 SATA▼5▲6 JTPM1 PCI_E6 JCI1 JFP1 JFP2 JAUD1 SYS_FAN1 SYS_FAN3 JUSB1 JCOM1 JUSB2...
  • Seite 55: Cpu Sockel

    Sie jedoch bitte sicher, dass die betroffenen Komponenten mit den abweichenden Einstellungen während des Übertaktens zurecht kommen. Von jedem Versuch des Betriebes außerhalb der Produktspezifikationen kann nur abgeraten werden. MSI übernehmt keinerlei Garantie für die Schäden und Risiken, die aus einem unzulässigem Betrieb oder einem Betrieb außerhalb der Produktspezifikation resultieren.
  • Seite 56: Dimm-Steckplätze

    DIMM-Steckplätze DIMMA1 DIMMB1 Kanal A Kanal B DIMMA2 DIMMB2 Speichermodul-Installationsempfehlung DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Wichtig Um einen sicheren Systemstart zu gewährleisten, bestücken Sie immer DIMMA2 zuerst. Aufgrund der Chipsatzressourcennutzung wird die verfügbare Kapazität des Speichers kleiner sein als die Größe der installierten Speicherkapazität. Basierend auf der Intel CPU Spezifikation wird eine Speicherspannung unter 1,35 Volt vorgeschlagen, um die CPU zu schützen.
  • Seite 57: Pci_E1~6: Pcie Erweiterungssteckplätze

    PCI_E1~6: PCIe Erweiterungssteckplätze PCI_E1: PCIe 3.0 x16 PCI_E2: PCIe 3.0 x1 PCI_E3: PCIe 3.0 x1 PCI_E4: PCIe 3.0 x4 PCI_E5: PCIe 3.0 x1 PCI_E6: PCIe 3.0 x1 Mehrere Grafikkarten Einbauempfehlung Wichtig Für die Installation einer einzelnen PCIe x16 Erweiterungskarte mit optimaler Leistung, empfehlen wir den PCI_E1 Steckplatz zu verwenden.
  • Seite 58: M2_1: M.2 Steckplatz (Key M)

    M2_1: M.2 Steckplatz (Key M) Wichtig Intel RST unterstützt nur PCIe M.2 SSD mit UEFI ® ROM, Legacy-ROM wird NICHT unterstützt. Intel Optane Technik. ® ™ Video Demonstration Eine anschauliche Darstellung zur Installation eines M.2 Moduls finden Sie im Video. http://youtu.be/JCTFABytrYA Installation eines M.2 Moduls Entfernen Sie die...
  • Seite 59: Sata1~6: Sata 6Gb/S Anschlüsse

    SATA1~6: SATA 6Gb/s Anschlüsse Dieser Anschluss basiert auf der Hochgeschwindigkeitsschnittstelle SATA 6Gb/s. Pro Anschluss kann ein SATA Gerät angeschlossen werden. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Wichtig Der SATA1 Anschluss ist nicht verfügbar, wenn Sie ein M.2 SATA SSD Modul im M.2 Steckplatz installieren.
  • Seite 60: Cpu_Pwr1, Atx_Pwr1: Stromanschlüsse

    CPU_PWR1, ATX_PWR1: Stromanschlüsse Mit diesen Anschlüssen verbinden Sie die ATX Stromstecker. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground Wichtig Stellen Sie sicher, dass alle Anschlüsse mit den richtigen Anschlüssen des Netzteils verbunden sind, um einen stabilen Betrieb der Hauptplatine sicherzustellen.
  • Seite 61: Jusb1~2: Usb 2.0 Anschlüsse

    Bitte beachten Sie, dass Sie die mit VCC (Stromführende Leitung) und Ground (Erdleitung) bezeichneten Pins korrekt verbinden müssen, ansonsten kann es zu Schäden kommen. Um das iPad, iPhone und den iPod über USB-Anschlüsse aufzuladen, installieren Sie bitte die MSI SUPER CHARGER Software. ® JUSB3~4: USB 3.1 Gen1 Anschlüsse Mit diesen Anschlüssen können Sie die USB 3.1 Gen1 Anschlüsse auf dem Frontpanel...
  • Seite 62: Cpu_Fan1,Sys_Fan1~4, Pump_Fan1: Stromanschlüsse Für Lüfter

    CPU_FAN1,SYS_FAN1~4, PUMP_FAN1: Stromanschlüsse für Lüfter Diese Anschlüsse können im PWM (Pulse Width Modulation) Modus oder Spannungsmodus betrieben werden. Im PWM-Modus bieten die Lüfteranschlüsse konstante 12V Ausgang und regeln die Lüftergeschwindigkeit per Drehzahlsteuersignal. Im DC-Modus bestimmen die Lüfteranschlüsse die Lüftergeschwindigkeit durch Ändern der Spannung. Wenn Sie ein 3-Pin (Non-PWM) Lüfter an einen PWM-Modus Lüfteranschluss anschließen, läuft der Lüfter mit höchster Drehzahl und kann unangenehm laut werden.
  • Seite 63: Jaud1: Audioanschluss Des Frontpanels

    JAUD1: Audioanschluss des Frontpanels Dieser Anschluss ermöglicht den Anschluss von Audiobuchsen eines Frontpanels. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Gehäusekontaktanschluss Dieser Anschluss wird mit einem Kontaktschalter verbunden. Normal Löse den Gehäuseeingriff aus...
  • Seite 64: Jtpm1: Tpm Anschluss

    JTPM1: TPM Anschluss Dieser Anschluss wird für das TPM Modul (Trusted Platform Module) verwendet. Weitere Informationen über den Einsatz des optionalen TPM Modules entnehmen Sie bitte dem TPM Plattform Handbuch. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address &...
  • Seite 65: Jlpt1: Parallele Schnittstelle

    JLPT1: Parallele Schnittstelle Mit dieser Schnittstelle können Sie das optionale parallele Schnittstelle mit dem Einbausatze verbinden. RSTB# AFD# PRND0 ERR# PRND1 PINIT# PRND2 LPT_SLIN# PRND3 Ground PRND4 Ground PRND5 Ground PRND6 Ground PRND7 Ground ACK# Ground BUSY Ground Ground SLCT No Pin EZ Debug LED Diese LEDs zeigen den Status der Hauptkomponenten während des Boot-Vorgangs an.
  • Seite 66: Bios-Setup

    Während des BOOT-Vorgangs drücken Sie die Taste Delete, wenn die Meldung Press DEL key to enter Setup Menu, F11 to enter Boot Menu erscheint. Verwenden Sie die MSI FAST BOOT Anwendung. Klicken Sie die GO2BIOS-Taste und drücken OK. Das System startet neu und geht direkt ins BIOS.
  • Seite 67: Reset Des Bios

    Aktualisierung des BIOS mit dem M-FLASH-Programm Vorbereitung: Laden Sie bitte die neueste BIOS Version, die dem Motherboard-Modell entspricht, von der offiziellen MSI Website herunter und speichern Sie die BIOS-Datei auf USB-Flash- Laufwerk. BIOS-Aktualisierungsschritte: Drücken Sie während des POST-Vorgangs die Taste (Entf), um das BIOS zu öffnen.
  • Seite 68: Ez Modus

    EZ Modus Im EZ-Modus können Sie die Grundinformationen des Systems einsehen und grundlegende Einstellungen konfigurieren. Um sich die erweiterten BIOS- Einstellungen anzeigen zu lassen, aktivieren Sie bitte den Erweiterten Modus durch Drücken des Setup Modus Schalter oder der Funktionstaste F7. Screenshot Setup Modus Schalter XMP Schalter...
  • Seite 69 Systeminformationen - Diese zeigt CPU/ DDR-Frequenz, CPU/ MB-Temperatur, MB/ CPU-Typ, Speicherkapazität, CPU/ DDR-Spannung, BIOS-Version und Erstellungs-Datum. Boot-Geräte Prioritätsleiste - Sie können die Gerätesymbole verschieben, um die Startreihenfolge zu ändern. Die Bootreihenfolge sind mit “hoch” (links) bis “niedrig” (rechts) bezeichnet. Informationsanzeige - Klicken Sie auf die Schaltfläche CPU, Memory, Storage, Fan Info und Help auf der linken Seite, um die jeweiligen Informationen anzuzeigen.
  • Seite 70: Erweiterter Modus

    Erweiterter Modus Drücken Sie den Setup Modus Schalter oder die Funkionstaste F7, um zwischen dem EZ-Modus und Erweiterten-Modus im BIOS-Setup zu wechseln. Screenshot XMP Schalter Setup Modus Schalter Suchen Sprache System- information OC GENIE 4 Schalter Bootgeräte- Prioritätsleiste BIOS-Menü BIOS-Menü -Auswahl -Auswahl Menüanzeige...
  • Seite 71: Oc Menü

    OC Menü In diesem Menü können Benutzer das BIOS anpassen und das Mainboard übertakten. Bitte führen Sie nur Änderungen durch, wenn Sie sich über das Ergebnis im Klaren sind. Sie sollten Erfahrung beim Übertakten haben, da Sie sonst das Motherboard oder Komponenten des Systems beschädigen können.
  • Seite 72 CPU Ratio [Auto] Legen Sie den CPU-Multiplikator fest, um die CPU-Taktfrequenzen zu bestimmen. Diese Option kann nur geändert werden, wenn der Prozessor diese Funktion unterstützt. 1/2/3/4-Core Ratio Limit [Auto]* Hier können Sie den CPU Multiplikator für die verschiedenen aktiven Kerne einstellen. Diese Option erscheint nur, wenn eine CPU installiert ist, die diese Funktion unterstützt.
  • Seite 73 fEIST [Enabled]* Aktivieren oder deaktivieren Sie die Enhanced Intel SpeedStep Technologie. ® [Enabled] Aktiviert EIST, um die CPU-Spannung und Taktfrequenz dynamisch anzupassen. Diese Funktion kann den durchschnittlichen Stromverbrauch und die durchschnittliche Hitzeentwicklung verringern. [Disabled] Deaktiviert EIST. fIntel Turbo Boost [Enabled]* Aktivieren oder deaktivieren Sie Intel Turbo Boost.
  • Seite 74 Adjusted DRAM Frequency Zeigt die Speicherfrequenz an. Nur Anzeige – keine Änderung möglich. Memory Try It ! [Disabled] Die Option „Memory Try It! “ dient der Verbesserung der Speicherkompatibilität oder auch der Speicherleistung durch die Auswahl der optimierten Speicher- Voreinstellungen. Advanced DRAM Configuration Drücken Sie die Eingabetaste <Enter>, um das Untermenü...
  • Seite 75 CPU Core/ GT Voltage Mode [Auto]* Wählen Sie die Betriebmodi für diese CPU Core/ Ring-Spannungen aus. [Auto] Diese Einstellungen werden vom BIOS automatisch konfiguriert. [Adaptive Mode] Legt die adaptiven Spannungen zur Optimierung der System- Performance automatisch an. [Override Mode] Hier können Sie die Spannungen manuell einstellen. [Offset Mode] Hier können Sie die Offset-Spannung einstellen und den Modus der Offset-Spannung auswählen.
  • Seite 76 fDIMMA1/A2/B1/B2 Memory SPD Drücken Sie die Eingabetaste <Enter>, um das Untermenü aufzurufen. Das Untermenü zeigt die Informationen des verwendeten Speichers an. Nur Anzeige. CPU Features Drücken Sie die Eingabetaste <Enter>, um das Untermenü aufzurufen. fHyper-Threading [Enabled] Die Intel Hyper-Threading Technologie behandelt die Prozessorkerne innerhalb des Prozessors als multi-logische Prozessoren, die Anweisungen simultan durchführen können.
  • Seite 77 fAdjacent Cache Line Prefetch [Enabled] Aktiviert oder deaktiviert den CPU Hardware Prefetcher (MLC Spatial prefetcher). [Enabled] Ermöglicht Adjacent Cache Line Prefetch zur Verringerung der Cache Latenzzeit und zur Leistungssteigerung von Applikationen. [Disabled] Aktiviert nur die angeforderten Cache-Zeilen. fCPU AES Instructions [Enabled] Aktiviert oder deaktiviert die CPU AES (Advanced Encryption Standard-New Instructions) Unterstützung.
  • Seite 78 fEIST [Enabled] Aktivieren oder deaktivieren Sie die Enhanced Intel SpeedStep Technologie. Diese ® Option wird angezeigt, wenn OC Explore Mode auf Normal eingestellt. [Enabled] Aktiviert EIST, um die CPU-Spannung und Taktfrequenz dynamisch anzupassen. Es kann zu verringern durchschnittliche Stromverbrauch und die durchschnittliche Wärmeproduktion. [Disabled] Deaktiviert EIST.
  • Seite 79: Softwarebeschreibung

    Softwarebeschreibung Laden Sie die neuesten Treiber und Dienstprogramme von www.msi.com herunter und aktualisieren Sie sie. Installation von Windows 7/ 8.1/ 10 ® Schalten Sie den Computer ein. Legen Sie die Windows 7/ 8.1/ 10 Disk in das optisches Laufwerk. ®...
  • Seite 80: Installation Von Utilities

    Installation von Utilities Bevor Sie Anwendungen installieren, müssen Sie die Treiber-Installation vollständig beendet haben. Legen Sie die MSI Treiber Disk in das optisches Laufwerk. ® Der Installer wird automatisch erscheint. Klicken Sie auf Utilities. Wählen Sie die Dienstprogramme, die installiert werden soll.
  • Seite 81 Table des matières Informations de sécurité ..................2 Spécifications ......................3 Panneau arrière Entrée/ Sortie ................7 Tableau explicatif de l’ état de la LED du port LAN ..........7 Configuration des ports audio ................7 Realtek HD Audio Manager ..................8 Vue d’...
  • Seite 82: Informations De Sécurité

    Informations de sécurité Les composants dans l’ emballage peuvent être endommagés par des décharges électrostatiques (ESD). Pour vous assurer de correctement monter votre ordinateur, veuillez vous référer aux instructions ci-dessous. Assurez-vous de bien connecter tous les composants. En cas de mauvaise connexion, il se peut que l’...
  • Seite 83: Spécifications

    7ème génération. Avant d’ utiliser les ® modules de mémoire Intel Optane™, veuillez vous assurer d’ avoir mis à jour ® les pilotes et le BIOS avec la dernière version disponible sur le site officiel MSI. Suite du tableau sur la page suivante Spécifications...
  • Seite 84 Suite du tableau de la page précédente Chipset Intel Z270 ® RAID Support des architectures RAID 0, RAID1, RAID 5 et RAID 10 pour les périphériques de stockage SATA Chipset Intel Z270 ® 8 x ports USB 3.1 Gen1 SuperSpeed USB (4 ports ƒ...
  • Seite 85 BIOS UEFI AMI Fonctions BIOS ACPI 5.0, PnP 1.0a, SM BIOS 2.8 Multilingue Pilotes SUPER CHARGER FAST BOOT COMMAND CENTER LIVE UPDATE 6 MSI SMART TOOL Logiciel X-BOOST MYSTIC LIGHT RAMDISK NETWORK MANAGER CPU-Z MSI GAMING Intel Extreme Tuning Utility ®...
  • Seite 86 Suite du tableau de la page précédente Audio Boost Realtek LAN/ Network Manager Compatible Intel Optane Memory ® Turbo M.2 M.2 Genie Ventilateurs pour la pompe Contrôle des ventilateurs Steel Armor PCI-E Fonctions spéciales Technologie Muitl GPU - CrossFire DDR4 Boost OC Genie 4 X-Boost Military Class 5...
  • Seite 87: Panneau Arrière Entrée/ Sortie

    Panneau arrière Entrée/ Sortie Ports Audio Port PS/2 USB 3.1 Gen1 DisplayPort USB 2.0 DVI-D USB 3.1 Gen1 Tableau explicatif de l’ état de la LED du port LAN LED indiquant la connexion LED indiquant la vitesse et l’ activité Etat Description Etat...
  • Seite 88: Realtek Hd Audio Manager

    Realtek HD Audio Manager Après l’ installation du pilote Realtek HD Audio, l’ icône Realtek HD Audio Manager apparaît dans la barre des tâches du système. Double-cliquez sur l’ icône pour lancer le programme. Sélection du périphérique Paramètres avancés Etat des prises Jack Amélioration d’...
  • Seite 89 Ilustration de l’ utilisation des ports audio dédiés au casque et au microphone Ilustration de l’ utilisation du port audio dédié aux haut-parleurs AUDIO INPUT Ilustration de l’ utilisation des ports audio dédiés aux haut-parleurs 7.1 AUDIO INPUT Front Center/ Subwoofer Side Rear...
  • Seite 90: Vue D' Ensemble Des Composants

    Vue d’ ensemble des composants DIMMA1 SYS_FAN4 DIMMA2 CPU_FAN1 CPU_PWR1 DIMMB1 Socket DIMMB2 processeur PUMP_FAN1 SYS_FAN2 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA2 PCI_E3 SATA1 PCI_E4 JTBT1* SATA▼3▲4 PCI_E5 SATA▼5▲6 JTPM1 PCI_E6 JCI1 JFP1 JFP2 JAUD1 SYS_FAN1 SYS_FAN3 JUSB1...
  • Seite 91: Socket Processeur

    électrique. Veuillez garder le capot de protection du processeur après l’ installation du processeur. Selon les exigences de RMA (Return Merchandise Authorization), MSI n’ acceptera pas les cartes mère dont le capot de protection aura été retiré.
  • Seite 92: Slots Dimm

    Slots DIMM DIMMA1 DIMMB1 Canal A Canal B DIMMA2 DIMMB2 Installation recommandée de module mémoire DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Important Veuillez à toujours insérer un module de mémoire dans l’ emplacement DIMMA2 en premier. Du fait des ressources utilisées par le chipset, la capacité de mémoire disponible est un peu moins élevée que celle installée.
  • Seite 93: Pci_E1~6: Slots D'extension Pcie

    être modifié. Si vous installez une carte graphique lourde, il vous faut utiliser un outil comme la barre de support MSI Gaming Series pour supporter son poids et pour éviter la déformation du slot. Vue d’ ensemble des composants...
  • Seite 94: M2_1: Slot M.2 (Touche M)

    M2_1: Slot M.2 (Touche M) Important La technologie Intel RST supporte seulement un SSD ® M.2 PCIe avec une mémoire ROM UEFI. Intel Optane Memory Ready ® Vidéo de démonstration Référez-vous à la vidéo d’ instruction sur l’ installation du module M.2. http://youtu.be/JCTFABytrYA Installation du module M.2 Enlevez la vis de la vis de...
  • Seite 95: Sata1~6: Connecteurs Sata 6 Gb/S

    SATA1~6: Connecteurs SATA 6 Gb/s Ces connecteurs utilisent une interface SATA 6 Gb/s. Chaque connecteur peut être relié à un appareil SATA. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Important Le port SATA1 est indisponible lorsqu’ un SSD M.2 SATA est installé dans le slot M.2. Veuillez ne pas plier les câbles SATA à...
  • Seite 96: Cpu_Pwr1, Atx_Pwr1: Connecteurs D' Alimentation

    CPU_PWR1, ATX_PWR1: Connecteurs d’ alimentation Ces connecteurs vous permettent de relier une alimentation ATX. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground...
  • Seite 97: Jusb1~2: Connecteurs Usb 2.0

    Notez que les broches VCC et Terre doivent être branchées correctement afin d’ éviter tout dommage sur la carte mère. Pour recharger votre tablette, smartphone ou autre périphérique par l’ intermédiaire d’ un port USB, veuillez installer l’ utilitaire MSI SUPER CHARGER. ®...
  • Seite 98: Cpu_Fan1,Sys_Fan1~4, Pump_Fan1: Connecteurs Pour Ventilateurs

    CPU_FAN1,SYS_FAN1~4, PUMP_FAN1: Connecteurs pour ventilateurs Les connecteurs pour ventilateurs peuvent être utilisés en mode PWM (Pulse Width Modulation) et en mode DC. En mode PWM, les connecteurs fournissent une sortie de 12V constante et ajustent la vitesse des ventilateurs avec un signal de contrôle de vitesse.
  • Seite 99: Jaud1: Connecteur Audio Avant

    JAUD1: Connecteur audio avant Ce connecteur se lie aux jacks audio du panneau avant. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Connecteur intrusion châssis Ce connecteur est relié à un câble d’ interrupteur intrusion châssis. Normal Commencer l’...
  • Seite 100: Jtpm1: Connecteur De Module Tpm

    JTPM1: Connecteur de module TPM Ce connecteur est relié à un module TPM (Trusted Platform Module). Veuillez vous référer au manuel du module TPM pour plus d’ informations. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address &...
  • Seite 101: Jlpt1: Connecteur De Port Parallèle

    JLPT1: Connecteur de port parallèle Ce connecteur sert à connecter un support de port parallèle optionnel. RSTB# AFD# PRND0 ERR# PRND1 PINIT# PRND2 LPT_SLIN# PRND3 Ground PRND4 Ground PRND5 Ground PRND6 Ground PRND7 Ground ACK# Ground BUSY Ground Ground SLCT No Pin EZ Debug LED Ces LED indiquent l’...
  • Seite 102: Configuration Du Bios

    Menu, F11 to enter Boot Menu) sur l’ écran, veuillez appuyer sur la touche Suppr. Quand l’ ordinateur est déjà en marche, vous pouvez utiliser l’ application MSI FAST BOOT. Cliquez sur le bouton GO2BIOS puis sur OK. Le système redémarre et entre dans l’...
  • Seite 103: Réinitialiser Le Bios

    Avant la mise à jour : Veuillez télécharger la dernière version de BIOS compatible à votre carte mère sur le site MSI. Ensuite, veuillez sauvegarder le nouveau BIOS sur le lecteur flash USB. Mettre le BIOS à jour : Appuyez sur la touche Suppr pour entrer dans l’ interface Setup du BIOS pendant le processus de POST.
  • Seite 104: Ez Mode (Mode Simplifié)

    EZ Mode (mode simplifié) Le mode EZ vous fournit les informations basiques du système et vous permet de configurer les réglages de base. Si vous souhaitez configurer les réglages du BIOS, veuillez utiliser le mode Advanced en appuyant sur le switch Setup Mode (Interrupteur de modes de réglages) ou la touche de fonction F7.
  • Seite 105 Langue - vous permet de choisir la langue du BIOS. Informations du système - montre la vitesse et la tension du processeur et de la mémoire, la température du processeur et de la carte mère, le type de carte mère et de processeur, la capacité...
  • Seite 106: Advanced Mode (Mode Avancé)

    Advanced Mode (mode avancé) Appuyez sur le Setup Mode switch (interrupteur de modes de réglages) ou sur la touche de fonction F7 pour commuter entre le mode simplifié et le mode avancé. Capture Interrupteur de d’ écran modes de réglages Interrupteur XMP Recherche Langue...
  • Seite 107: Oc Menu (Menu Overclocking)

    OC Menu (menu overclocking) Ce menu est destiné aux utilisateurs avancés souhaitant overclocker leur carte mère. Important L’ overclocking manuel du PC n’ est recommandé que pour les utilisateurs avancés. L’ overclocking n’ est pas garanti et une mauvaise manipulation peut rendre nulle votre garantie et sévèrement endommager votre matériel.
  • Seite 108 CPU Ratio Mode [Dynamic Mode]* Choisit le mode d'opération du ratio du processeur. Ce menu apparaît lorsque vous réglez le ratio manuellement. [Fixed Mode] Fixe le ratio. [Dynamic Mode] Le ratio sera modifié dynamiquement selon la charge du processeur. CPU Ratio Offset When Running AVX [Auto] Définit une valeur de décalage pour réduire le ratio du cœur CPU.
  • Seite 109 CPU Base Clock Apply Mode [Auto]* Définit le mode d’ application pour le réglage de la fréquence de base du processeur. [Auto] Ce réglage est configuré automatiquement par le BIOS. [Next Boot] Le processeur fonctionne avec une fréquence de base paramétrée pour le prochain démarrage.
  • Seite 110 DigitALL Power Appuyez sur la touche Entrée pour entrer dans le sous-menu. Gère l’ alimentation numérique du contrôleur PWM du processeur. fCPU Loadline Calibration Control [Auto] La tension du processeur diminue proportionnellement à la charge du processeur. Une valeur plus élevée peut entraîner une tension plus élevée et de bonnes performances d'overclocking mais augmentera la température du processeur et du module de régulation de tension (VRM).
  • Seite 111 CPU Specifications Appuyez sur la touche Entrée pour accéder au sous-menu. Ce sous-menu affiche les caractéristiques du processeur installé. Vous pouvez également accéder à ce sous-menu à tout moment en appuyant sur la touche [F4]. Fonctionne uniquement en lecture seule. fCPU Technology Support Appuyez sur la touche Entrée pour accéder au sous-menu.
  • Seite 112 fIntel VT-D Tech [Disabled] Active ou désactive la technologie Intel VT-D (Intel Virtualization for Direct I/O). fHardware Prefetcher [Enabled] Active ou désactive le prefetcher matériel (MLC Streamer prefetcher). [Enabled] Permet au prefetcher matériel d'acquérir automatiquement les données et les instructions dans le cache L2 de la mémoire pour ajuster les performances du processeur.
  • Seite 113 fCFG Lock [Enabled] Verrouille ou déverrouille la fonction MSR 0xE2[15], CFG lock bit. [Enabled] Verrouille le CFG lock bit. [Disabled] Déverrouille le CFG lock bit. fEIST [Enabled] Active ou désactive Enhanced Intel SpeedStep Technology. Ce menu apparaît ® lorsque OC Explore Mode est mis en Normal. [Enabled] Active la technologie EIST pour ajuster la tension du processeur et de la fréquence du cœur de manière dynamique.
  • Seite 114: Informations Sur Les Logiciels

    Informations sur les logiciels Veuillez vous référer au site www.msi.com pour télécharger et mettre à jour les derniers utilitaires et pilotes. Installer Windows 7/ 8.1/ 10 ® Allumez l’ ordinateur Insérez le disque de Windows 7/ 8.1/ 10 dans le lecteur optique.
  • Seite 115 Содержание Безопасное использование продукции ............2 Технические характеристики ................ 3 Задняя панель портов ввода/ вывода ............7 Таблица состояний индикатора порта LAN ........... 7 Конфигурация портов Аудио ................7 Менеджер Realtek HD Audio ................8 Компоненты материнской платы ............... 10 Процессорный...
  • Seite 116: Безопасное Использование Продукции

    Безопасное использование продукции Компоненты, входящие в комплект поставки могут быть повреждены статическим электричеством. Для успешной сборки компьютера, пожалуйста, следуйте указаниям ниже. Убедитесь, что все компоненты компьютера подключены должным образом. Ослабленные соединения компонентов могут привести как к сбоям в работе, так и полной неработоспособности компьютера. Чтобы...
  • Seite 117: Технические Характеристики

    3600(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2600(OC)/ 2400(OC)/ 2133 МГц* Двухканальная архитектура памяти Поддержка Intel Extreme Memory Profile (XMP) ® * Пожалуйста, обратитесь www.msi.com для получения дополнительной информации о совместимых памяти. 2x слота PCIe 3.0 x16 (Поддержка x16/x4) Слоты расширения 4x слота PCIe 3.0 x1 1x порт...
  • Seite 118: Разъемы Задней Панели

    процессоров 7-го поколения. Перед использованием модулей памяти , пожалуйста, убедитесь, что драйверы и BIOS были Intel Optane ® ™ обновлены до последней версии с веб-сайта MSI. Чипсет Intel Z270 ® Поддержка RAID 0, RAID 1, RAID 5 и RAID 10 для RAID устройств...
  • Seite 119 Продолжение с предыдущей страницы 1x 24-контактный разъем питания ATX 1x 8-контактный разъем питания ATX 12В 6x разъемов SATA 6ГБ/с 2x разъема USB 3.1 Gen1 (Поддержка 4-х дополнительных портов USB 3.1 Gen1) 2x разъема USB 2.0 (Поддержка 4-х дополнительных портов USB 2.0) 1x 4-контактный...
  • Seite 120 Продолжение с предыдущей страницы Драйверы SUPER CHARGER FAST BOOT COMMAND CENTER LIVE UPDATE 6 MSI SMART TOOL Программное обеспечение X-BOOST MYSTIC LIGHT RAMDISK NETWORK MANAGER CPU-Z MSI GAMING Intel Extreme Tuning Utility ® Norton Internet Security Solution ™ Google Chrome , Google Toolbar, Google Drive ™...
  • Seite 121: Задняя Панель Портов Ввода/ Вывода

    Задняя панель портов ввода/ вывода Порты Аудио Порт PS/2 USB 3.1 Gen1 DisplayPort USB 2.0 DVI-D USB 3.1 Gen1 Таблица состояний индикатора порта LAN Подключение/ Работа Скорость передачи данных индикатора Состояние Описание Состояние Описание Выкл. 10 Мбит/с подключение Выкл. Не подключен Зеленый...
  • Seite 122: Менеджер Realtek Hd Audio

    Менеджер Realtek HD Audio После установки драйвера Realtek HD Audio, в системном трее появится значок Realtek HD Audio Manager. Дважды щелкните по значку для запуска приложения. Выбор устройства Расширенные настройки Состояние разъемов Дополнительные эффекты Мастер- Настройки громкость подключений Профили Выбор устройства - позволяет выбрать источник аудио выхода и изменить...
  • Seite 123 Подключение наушников и микрофона Подключение внешнего стерео усилителя (колонок) AUDIO INPUT Подключение звуковой системы 7.1 AUDIO INPUT Front Center/ Subwoofer Side Rear Задняя панель портов ввода/ вывода...
  • Seite 124: Компоненты Материнской Платы

    Компоненты материнской платы DIMMA1 SYS_FAN4 DIMMA2 CPU_FAN1 Процессорный CPU_PWR1 DIMMB1 сокет DIMMB2 PUMP_FAN1 SYS_FAN2 EZ Debug LED ATX_PWR1 JUSB3 M2_1 JBAT1 PCI_E1 JUSB4 PCI_E2 SATA2 PCI_E3 SATA1 PCI_E4 JTBT1* SATA▼3▲4 PCI_E5 SATA▼5▲6 JTPM1 PCI_E6 JCI1 JFP1 JFP2 JAUD1 SYS_FAN1 SYS_FAN3 JUSB1 JCOM1 JUSB2...
  • Seite 125: Процессорный Сокет

    кабель питания. Пожалуйста, сохраните защитную крышку процессорного сокета после установки процессора. Любые возможные гарантийные случаи, связанные с работой материнской платы, MSI будет рассматривать только, при наличии защитной крышки на процессорном сокете. При установке процессора обязательно установите процессорный кулер. Кулер, представляющий собой систему охлаждения процессора, предупреждает...
  • Seite 126: Слоты Dimm

    Слоты DIMM DIMMA1 DIMMB1 Канал A Канал B DIMMA2 DIMMB2 Рекомендации по установке модулей памяти DIMMB2 DIMMB2 DIMMB1 DIMMA2 DIMMA2 DIMMA2 DIMMA1 Внимание! Всегда устанавливайте модуль памяти сначала в слот DIMMA2. В связи со спецификой использования ресурсов чипсета, доступный объем памяти будет немного меньше, чем объем установленный. На...
  • Seite 127: Pci_E1~6: Слоты Расширения Pcie

    на карту расширения и выполните необходимые дополнительные аппаратные или программные изменения для данной карты. При установке массивной видеокарты, необходимо использовать такой инструмент, как MSI Gaming Series Graphics Card Bolster для поддержки веса графической карты и во избежание деформации слота. Компоненты материнской платы...
  • Seite 128: M2_1: Разъем M.2 (Ключ M)

    M2_1: Разъем M.2 (Ключ M) Внимание! RST поддерживает только PCIe M.2 SSD с Intel ® UEFI ROM. Поддержка Intel Optane Memory. ® ™ Видео Инструкция Смотрите видео, чтобы узнать как установить модуль M.2. http://youtu.be/JCTFABytrYA Установка модуля M.2 Выкрутите винт из стойки.
  • Seite 129: Sata1~6: Разъемы Sata 6 Гб/С

    SATA1~6: Разъемы SATA 6 Гб/с Эти разъемы представляют собой интерфейсные порты SATA 6 Гб/с. К каждому порту можно подключить одно устройство SATA. SATA2 SATA1 SATA4 SATA3 SATA6 SATA5 Внимание! Порт SATA1 будет недоступен при установке модуля M.2 SATA SSD в разъеме...
  • Seite 130: Cpu_Pwr1, Atx_Pwr1: Разъемы Питания

    CPU_PWR1, ATX_PWR1: Разъемы питания Данные разъемы предназначены для подключения блока питания ATX. CPU_PWR1 Ground +12V Ground +12V Ground +12V Ground +12V +3.3V +3.3V +3.3V -12V Ground Ground PS-ON# Ground Ground Ground ATX_PWR1 Ground Ground PWR OK 5VSB +12V +12V +3.3V Ground Внимание! Для...
  • Seite 131: Jusb1~2: Разъемы Usb 2.0

    Внимание! Помните, что во избежание повреждений, необходимо правильно подключать контакты VCC и земли. Для того, чтобы зарядить ваш iPad, iPhone и iPod через порты USB, пожалуйста, установите утилиту MSI SUPER CHARGER. ® JUSB3~4: Разъемы USB 3.1 Gen1 Данные разъемы предназначены для подключения портов USB 3.1 Gen1 на...
  • Seite 132: Cpu_Fan1,Sys_Fan1~4, Pump_Fan1: Разъемы Вентиляторов

    CPU_FAN1,SYS_FAN1~4, PUMP_FAN1: Разъемы вентиляторов Разъемы вентиляторов можно разделить на два типа: с PWM (PulseWidth Modulation) управлением и управлением постоянным током. Разъемы вентиляторов с PWM управлением имеют контакт с постоянным напряжением 12В, а также контакт с сигналом управления скоростью вращения. Управление скоростью вращения вентиляторов с управлением постоянным...
  • Seite 133: Jaud1: Разъем Аудио Передней Панели

    JAUD1: Разъем аудио передней панели Данный разъем предназначен для подключения аудиоразъемов передней панели. MIC L Ground MIC R Head Phone R MIC Detection SENSE_SEND No Pin Head Phone L Head Phone Detection JCI1: Разъем датчика открытия корпуса К этому разъему подключается кабель от датчика открытия корпуса. Нормально...
  • Seite 134: Jtpm1: Разъем Модуля Tpm

    JTPM1: Разъем модуля TPM Данный разъем используется для подключения модуля ТРМ (Trusted Platform Module). Дополнительные сведения см. в описании модуля ТРМ. LPC Clock 3V Standby power LPC Reset 3.3V Power LPC address & data pin0 Serial IRQ LPC address & data pin1 5V Power LPC address &...
  • Seite 135: Jlpt1: Разъем Последовательного Порта

    JLPT1: Разъем последовательного порта Данный разъем позволяет подключить последовательный порт, размещенный на внешнем бракете. RSTB# AFD# PRND0 ERR# PRND1 PINIT# PRND2 LPT_SLIN# PRND3 Ground PRND4 Ground PRND5 Ground PRND6 Ground PRND7 Ground ACK# Ground BUSY Ground Ground SLCT No Pin Индикаторы...
  • Seite 136: Настройка Bios

    Нажмите клавишу Delete, когда появляется сообщение на экране Press DEL key to enter Setup Menu, F11 to enter Boot Menu во время загрузки. При помощи приложения MSI FAST BOOT. Нажмите на кнопку GO2BIOS и выберите ОК. Система перезагрузится и автоматически войдет в...
  • Seite 137: Сброс Bios

    обратитесь к разделу Джампер очистки данных CMOS. Обновление BIOS Обновление BIOS при помощи M-FLASH Подготовительные операции: Пожалуйста, скачайте последнюю версию файла BIOS с сайта MSI, который соответствует вашей модели материнской платы. Сохраните файл BIOS в флэш-диске USB. Обновление BIOS: Нажмите клавишу Del для входа в настройки BIOS во время процедуры...
  • Seite 138: Режим Ez

    Режим EZ Режим EZ предоставляет основную информацию о системе и позволяет выполнить основные операции по настройке. Для настройки расширенных функций BIOS, пожалуйста, войдите в Расширенный режим, путем нажатия Переключатель режимов установки или при помощи функциональной клавиши F7. Переключатель Скриншот режимов установки Переключатель...
  • Seite 139 Язык - позволяет выбрать язык интерфейса для настройки BIOS. Информация о системе - показывает частоту процессора/ памяти, температуру процессора/ материнской платы, информацию о материнской плате/процессоре, размер памяти, напряжение на процессоре/ памяти, версию BIOS и дату создания. Приоритет загрузочных устройств - вы можете переместить инонку устройства...
  • Seite 140: Режим Разгона

    Режим разгона Нажмите переключатель режимов установки или функциональную клавишу F7 для переключения между режимами EZ и разгона в настройках BIOS. Переключатель Скриншот режимов установки Переключатель XMP Поиск Язык Информация о системе Переключатель Приоритет OC GENIE 4 загрузочных устройств Выбор меню Выбор...
  • Seite 141: Меню Oc

    Меню OC Данное меню предназначено для опытных пользователей и предоставляет возможности для «разгона» системы. Внимание! Разгонять ПК вручную рекомендуется только опытным пользователям. Производитель не гарантирует успешность разгона. Неправильное выполнение разгона может привести к аннулированию гарантии и серьезному повреждению оборудования. Неопытным пользователям рекомендуется использовать функцию OC GENIE 4.
  • Seite 142 Adjusted CPU Frequency Показывает текущую частоту процессора. Это значение нельзя изменять. CPU Ratio Mode [Dynamic Mode]* Выбор множителя процессора. Этот пункт появляется при установке множителя процессора вручную. Фиксирует множитель процессора. [Fixed Mode] Множитель процессора будет меняться в зависимости от [Dynamic Mode] загрузки...
  • Seite 143 CPU Base Clock (MHz) Установка базовой тактовой частоты процессора. Изменение этого параметра обеспечивает возможность «разгона» процессора. Обращаем ваше внимание, что успешность разгона и стабильная работа системы при этом не гарантируется. Этот пункт появляется, если установленный процессор поддерживает данную функцию. CPU Base Clock Apply Mode [Auto]* Устанавливает...
  • Seite 144 Memory Fast Boot [Auto]* Включает или выключает инициализацию и тренировку памяти при каждой загрузке. Этот параметр будет настроен автоматически с помощью BIOS. [Auto] Система будет сохранять настройки, определенные при [Enabled] первой инициализации и тренировке памяти. Оперативная память более не будет подвергаться процессу инициализации и...
  • Seite 145 DRAM Voltages control [Auto] Эти параметры позволяют вам задать напряжения, связанные с памятью. При установке в Auto, BIOS установит напряжения автоматически. Вы также можете настроить напряжения вручную. PCH Voltages control [Auto] (optional) Эти параметры позволяют вам задать напряжения, связанные с PCH. При установке...
  • Seite 146 fLimit CPUID Maximum [Disabled] Включение или выключение расширенных значений CPUID. BIOS будет ограничивать максимальное входное значение [Enabled] CPUID для обхода проблемы загрузки в устаревших операционных системах, не поддерживающих процессор с расширенными значениями CPUID. Используйте фактическое максимальное входное значение [Disabled] CPUID. fIntel Virtualization Tech [Enabled] Включение...
  • Seite 147 fIntel C-State [Auto] Включение или выключение Intel C-state. C-state - это технология управления питанием процессора, определяемая ACPI. Параметр будет настроен автоматически с помощью BIOS. [Auto] Определяет состояние простоя системы и значительно [Enabled] сокращает энергопотребление процессором. Выключение функции. [Disabled] fC1E Support [Disabled] Включение...
  • Seite 148 fLong Duration Maintained (s) [Auto] Настроить максимальное время работы процессора с ограничением мощности при Long Duration Power Limit. fShort Duration Power Limit (W) [Auto] Настроить предельную мощность TDP процессора при кратковременных нагрузках в режиме Turbo Boost. fCPU Current Limit (A) [Auto] Устанавливает...
  • Seite 149: Описание Программного Обеспечения

    Описание программного обеспечения Cкачайте и обновите последние утилиты и драйвера с сайта: www.msi.com Установка Windows 7/ 8.1/ 10 ® Включите компьютер. Вставьте диск Windows 7/ 8.1/ 10 в привод для оптических дисков. ® Примечание: Из-за ограничений, накладываемых установщиком 7, USB оптические приводы и флеш накопители не...
  • Seite 150: Установка Утилит

    Установка утилит Перед установкой утилиты необходимо выполнить установку драйверов. Вставьте диск с драйверами MSI Driver Disc в привод для оптических ® дисков. Автоматически отобразится окно установщика. Нажмите вкладку Utilities. Выберите необходимые для установки утилиты. Нажмите кнопку Install. Начнется установка программного обеспечения. После ее завершения...
  • Seite 151: Regulatory Notices

    EU REACH Regulation (Regulation EC No. 1907/2006 of the European Parliament and the This device complies with part 15 of the FCC Rules. Council), MSI provides the information of chemical Operation is subject to the following two conditions: substances in products at: (1) This device may not cause harmful interference, and http://www.msi.com/html/popup/csr/evmtprtt_pcm.
  • Seite 152 MSI will comply with the product take entregar a una empresa autorizada para la recogida de back requirements at the end of life of MSI-branded estos residuos.
  • Seite 153: Environmental Policy

    MSI si adeguerà a tale Direttiva ritirando tutti i prodotti marchiati MSI che sono stati venduti all’interno dell’Unione Europea alla fine del loro ciclo di vita.
  • Seite 154: Revision History

    Alternatively, please try the following help resources for further guidance. y Visit the MSI website for technical guide, BIOS updates, driver updates, and other information: http://www.msi.com y Register your product at: http://register.msi.com...

Inhaltsverzeichnis
