2.2

General information on the electrical installation

Note:
Ensure correct connection. If the equipment is incorrectly connected, the warranty cover will not be
applicable.
Admissible load of the control system's power supply unit with external devices 24 V DC:
Table 3: Current consumption of devices typically connected to the control unit
Holding magnet model 828
Emergency exit strike model 331 RR AKRR
Swing door strike 351 AKRR
Holding magnet model 827
Door terminal model 1337-10/11
Terminal module 1370-10
Control unit model 1332-10/11
Flash lamp model 1055-24
Piezo horn model 1037-10
Smoke detector model 60030
EMC protection:
‡
Shielded conductors must be used. All cable shields must be mounted on one side on the
grounding bar provided in the control unit housing for this purpose.
Control cables:
‡
Length max. 300m, minimum diameter 0.6mm.
Cables to the locking element:
‡
Length max. 300m.
‡
The cable cross section must be dimensioned so that a voltage of 24 V is active at the live locking
element.
‡
It is possible to set an increase of the output voltage by around +10% (load-dependent) at
potentiometer PO1 to balance out the conductor loss.
All control and display elements and cables shown in dotted lines in the terminal diagrams may be
optionally connected.
Ensure adherence to the valid VDE regulations and the stipulations of the local energy utility companies.
max 1.1 A
315 mA
160 mA
160 mA
250 mA
60 mA
60 mA
50 mA
250 mA
20 mA
3 mA
D0019203T0000300
61
