As the colours of the wire in the mains lead of
this appliance may not correspond with the
colour markings identifying the terminals on
your plug, proceed as follows:
The wire which is coloured BLUE must be
connected to the terminal which is marked
with the letter N or coloured black.
The wire which is coloured BROWN must be
connected to the terminal which is marked
with the letter L or coloured red.
The wire which is coloured GREEN/YELLOW
must be connected to the terminal which is
marked with the letter E or (earth symbol) and
is coloured GREEN or GREEN/YELLOW.
If a 13Amp (BS1363) plug is used, a 13Amp
(BS1362) fuse must be fitted, or if any other
type of plug is used, a 13Amp fuse must be
fitted, either in the plug or adaptor, or on the
distribution board.
Warning! This appliance must be earthed.
Description (fig. A)
Your 110402 Princess Table Chef has been
designed for frying or grilling food without
using fat. The appliance is equipped with
a grill plate with a non-stick coating.
The appliance is suitable for indoor and
outdoor use.
1. Thermostat
2. Thermostat dial
3. Temperature indicator
4. Thermostat socket
5. Grill plate
6. Table
7. Extension table
8. Base rack
9. Leg
Initial use
Preparation
•
Clean the grill plate with a damp cloth.
•
Thoroughly dry the grill plate.
Assembly
Warning!
- Before assembly, always remove the
mains plug from the wall socket.
Assembling the appliance
(fig. B1 & B2)
•
Mount the lower base rack (8) to the first
pair of legs (9). Manually tighten the
screws (10).
•
Mount the upper base rack (8) to the first
pair of legs (9). Manually tighten the
screws (10).
•
Mount the lower base rack (8) to the
second pair of legs (9). Manually tighten
the screws (10).
•
Mount the upper base rack (8) to the
second pair of legs (9). Manually tighten
the screws (10).
•
Firmly tighten the screws (10) using
a screwdriver.
•
Mount the table (6) to the top of the legs
(9). Firmly tighten the screws (11) using
a screwdriver.
Mounting the extension table
(fig. C)
•
Mount the extension table (7) to the side of
the table (6) as shown.
•
Insert the pins (12) into the holes (13) of
the folding arms (14). Manually tighten the
nuts (15).
•
Firmly tighten the screws (16) to the table
(6) and the extension table (7) using
a screwdriver.
•
Firmly tighten the nuts (15) using a
spanner.
Folding and unfolding the
extension table (fig. C)
•
To fold the extension table, loosen the
locking nuts (17) and lower the extension
table (7).
•
To unfold the extension table, raise the
extension table (7) and tighten the locking
nuts (17).
