EN
English
1. Technical Data (see Fig 2.)
Stroke per min.
Model
1
[mm]
max pressure 6.3 bar (90 psi)
a :Vibration level, k Uncertainty ; L
hd
Declaration of noise (ISO 15744) and vibration emission (ISO 28927-7)
All values are current as of the date of this publication. For the latest information please visit www.rodcraft.com.
These declared values were obtained by laboratory type testing in accordance with the stated standards and are suitable for comparison with the declared va-
lues of other tools tested in accordance with the same standards. These declared values are not adequate for use in risk assessments and values measured
in individual work places may be higher. The actual exposure values and risk of harm experienced by an individual user are unique and depend upon the way
the user works, the workpiece and the workstation design, as well upon the exposure time and the physical condition of the user.
We, RODCRAFT PNEUMATIC TOOLS , cannot be held liable for the consequences of using the declared values, instead of values reflecting the actual
exposure, in an individual risk assessment in a work place situation over which we have no control.
This tool may cause hand-arm vibration syndrome if its use is not adequately managed. An EU guide to managing hand-arm vibration can be found at www.
pneurop.eu/uploads/documents/pdf/PN3-02-NV_Declaration_info_sheet_0111.pdf
We recommend a programme of health surveillance to detect early symptoms which may relate to noise or vibration exposure, so that management proce-
dures can be modified to help prevent future impairment.
2. Machine Type
• This product is designed for cutting sheet, metal and plastic. No other use permitted. For professional use only.
• Please read the product safety information carefully!
3. Implementation and Operation
• Connect device as shown in Fig.01.
• Fix the accessories properly to the tool.
• To start the machine, simply pull the trigger (A). Machine speed is increase by increasing pressure on the trigger. Release the trigger to stop.
4. Lubrication
• Motor Lubrication
Use an air line lubricator with SAE #10 oil, adjusted to two (2) drops per minute.
If an air line lubricator cannot be used, add air motor oil to the inlet once a day.
5. Maintenance
• Follow local country environmental regulations for safe handling and disposal of all components
• Disassemble and inspect the tool every three 3 months if the tool is used every day. Replace damaged or worn parts.
• Always ensure that the machine is disconnected from energy source (compressed air) to avoid accidental operation.
• High wear parts are underlined in the parts list.
• To keep downtime to a minimum, the following service kits are recommended:
Tune-Up Kit: see part list
6. Disposal
• The disposal of this equipment must follow the legislation of the respective country.
• All damaged, badly worn or improperly functioning devices MUST BE TAKEN OUT OF OPERATION.
• Repair only by technical maintenance staff.
7. EU Declaration of conformity
We : Rodcraft Customer Center Langemarckstr.35 bis 45141 Essen- Germany
Declare that the product(s): Saw
Machine type(s) : RC6050 & RC6051
Origin of the product : Taiwan
is in conformity with the requirements of the council Directives on the approximation of the laws of the Member States relating : to "Machinery" 2006/42/EC (17/05/2006)
applicable harmonised standard(s) : EN ISO 11148-12 : 2012
Name and position of issuer : Pascal Roussy (R&D Manager)
Place & Date : Saint-Herblain, 12/2016
Technical file available from EU headquarter. Pascal Roussy R&D Manager LLC CP Technocenter 38, rue Bobby Sands - BP10273 44800 Saint Herblain - France
Copyright 2016, Rodcraft
All rights reserved. Any unauthorized use or copying of the contents or part there of is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings.
Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability.
Original instructions
Inner Horse Dia Net Weight
2 4
[mm] [kg]
Sound pressure level dB(A), K
pA
Serial Number: 001 - 999
SoundPressure
Air Inlet
L
pA
5
[inch] [dB(A)]
= K = 3 dB Uncertainty.
pA WA
RC6050 & RC6051
SoundPower
L
ahd
wA
6 7
[dB(A)] [m/s²]
Saw
Vibrations
k
8
[m/s²]
