Diamond RBB/2+2 Montageanleitung Seite 12

Insert the sleeve in the inferior side of the doors (fig. 7);
Fix the doors (right-side and/or left-side) to the bottom and top panels (Fig. 8);
Fix the pillar to the top and bottom panels (Fig.9);
Fasten the superior camlocks on both side panels.
Insert the covers in the side panels (Fig. 10-a)and in the bottom panel (Fig. 10-b);
