INSTALLATION AND MAINTENANCE INSTRUCTIONS
7100XE FAAST
Fire Alarm Aspiration Sensing Technology
SPECIFICATIONS
Electrical Characteristics
External Supply Voltage
Remote Reset Time
Power Reset
Relay Contact Ratings
Environmental Ratings
Operating Temperature
Sampled Air Temperature
Humidity
The purpose of this document is to provide practical information for mounting
and connecting to FAAST XS. For full product information, which includes in-
stallation guidelines, instructions for safe use, and warranty and safety informa-
tion, refer to the FAAST XS Comprehensive User Guide (E56-0501) available at
systemsensor.com/7100XEuserguide or by scanning the QR code.
ITEMS INCLUDED WITH UNIT
• FAAST XS (7100XE) device
• Mounting bracket and hardware
• Installation and Maintenance Instructions
• USB interface cable
• EMI Filter Assembly
PipeIQ® software, user guides, and other helpful documents are available at
systemsensor.com/faast.
CONNECTING TO FAAST XS
FAAST XS requires a valid configuration from PipeIQ in order to initialize. The
device must be connected to a PC running PipeIQ with either the USB port, or
the Ethernet port located inside the wiring compartment of the unit.
CONNECTING TO FAAST XS VIA USB
NOTE: In order to connect your computer to the FAAST XS using a USB con-
nection, a USB driver must first be installed. The driver installation occurs
during the installation of PipeIQ version 2.6 or later. Once the driver is in-
stalled, connect to the device using the following steps.
1. Launch PipeIQ. (Download from systemsensor.com/faast.)
2. Create a new project and select FAAST XS device, or open an existing project
3. Expand the tree view in the left side navigation pane to reveal the device
4. Right click on the device and select 'Connect Device'
5. Select USB, The USB combo box should already be populated with FAAST
XS (COM Port Number).
6. Select 'Admin' and enter the password – the default password is 'password'
– then click 'Connect'.
CONNECTING TO FAAST XS VIA ETHERNET
Default Device IP Configuration
IP Address: 192.168.1.10
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.1.1
Primary DNS: 0.0.0.0
Secondary DNS: 0.0.0.0
CONFIGURE YOUR PC
Your PC will need to be sitting on the same local area network as the FAAST
XS device in order to establish communication. Change your PC's IP address to
192.168.1.15 by:
1. Accessing your network setting in your PC's control panel
2. Open 'Local Area Connection' settings and select 'Properties'
3. Select 'Internet Protocol Version 4 (TCP/IPv4) and then select 'Properties'
18 – 30 VDC
External monitor must be pulled low for a minimum of 100 msec
1 sec
3.0A @ 30VDC, 0.5A @125VAC
0°C to 38°C – Factory tested to 55°C
-20°C to 60°C
10 to 95% non-condensing
®
4. Select 'Use the following IP address and enter 192.168.1.15. If the subnet
mask does not automatically populate, enter 255.255.255.0 into the subnet
mask field.
5. Click OK and close out of the network menus.
Important Note: Before changing your PC's IP address, be sure to take note of
whether your IP is currently dynamically set, or is a static IP address. If your PC
is assigned a static IP address, make note of all IP address and settings so that
you can change back to the proper settings after the FAAST has been configured.
CONNECT USING PIPEIQ
1. Launch PipeIQ. (Download from systemsensor.com/faast.)
2. Create and save a new project, or open an existing projectx
3. Expand the tree view in the left side navigation pane to reveal the device
4. Right click on the device and select 'Connect Device'
5. Select Host/IP and type in the device's IP address - default is 192.168.1.10
6. Select 'Admin' and enter the password – the default password is
'pass word' – then click 'Connect'.
7. Upon connection, a green dot will appear on the device icon in the
navigation tree.
INSTALLATION
This equipment must be installed in accordance with all local and national
codes and regulations.
PIPE INSTALLATION
The pipe layout is designed using the PipeIQ software package. To design
the pipe network, refer to the Aspirating Smoke Detector Pipe Installation
Guide (available at systemsensor.com/faast). All pipe must be installed in ac-
cordance with local and national codes and regulations. The pipe network
should be complete before proceeding with the physical and electrical system
installation.
To maintain compliance with EN54-20, all pipes and accessories used with
FAAST XS must comply to clause 5.7 of EN54-20.
PHYSICAL UNIT INSTALLATION
Make sure that there are no pipes or electrical wires within the wall before
drilling any mounting holes
SECURING THE MOUNTING BRACKET
The typical mounting location for the FAAST XS unit is on the wall. The unit is
mounted to the wall using the enclosed mounting bracket. Figure 1 shows the
wall mounting bracket. For easier access to the FAAST XS unit, it is preferred
to position the mounting bracket in an easily accessible location.
1. Place the mounting bracket on the wall in the desired location and use it as
a template to locate the necessary mounting holes.
2. Mark the hole locations and remove the bracket. It is recommended to se-
cure the bracket using both mounting holes.
