If not used for a longer period of time (e.g. for storage), remove the batteries (or
rechargeable batteries) inserted in the transmitter to avoid damage from leaking
batteries/rechargeable batteries.
Special information for Lithium Polymer – Batteries
-
After the flight, the flight battery must be disconnected from the model. Do not leave the
flight battery connected to the model if you do not use it (e.g. during transport or storage).
Otherwise, the flight battery may be fully discharged and is thus destroyed/unusable!
-
Remove the flight battery that is to be charged from the model and place it on a fire-proof
support. Keep a distance to flammable objects.
-
Only use a suitable charger with balancer for charging the LiPo flight battery. Observe the
information of the charger manufacturer, read the operating instructions very carefully.
Disconnect the flight battery from the charger when the rechargeable battery is fully charged.
-
Never charge the enclosed flight battery immediately after use. Always let the flight battery
to cool down until it has reached room or ambient temperature again. The same applies for
the charging process; This will cause the flight battery to heat up.
-
Only recharge the flight battery when it is intact and undamaged. If the external insulation of
the rechargeable battery is damaged or if the rechargeable battery is deformed or bloated, it
must not be charged. In this case, there is immediate danger of fire and explosion!
-
Recharge the rechargeable batteries about every 3 months, because otherwise there may be
a total discharge due to self-discharge, which makes the rechargeable batteries useless.
-
Never damage the flight battery covering, do not cut the foil cover, do not probe the
rechargeable battery with sharp objects. There is a risk of fire and explosion!
-
The flight battery must not get damp or wet. There is a risk of fire and explosion!
-
Do not expose the flight battery to any high/low temperatures or to direct solar radiation.

2. Technische Daten / Technical Data:

Gleitschirm / Paraglider:
Spannweite ausgelegt / material spread:
Spannweite projiziert / projected spread:
Fläche ausgelegt / material total surface area: 1,28 m²
Fläche projiziert / projected total surface area: ca. 1,1 m²
Leinenmaterial / line material:
Abfluggewicht / All up weight:
Rucksackmotor / Paramotor:
Motor / motor:
Steller / ESC:
Propeller / Propeller:
Anleitung / Manual Hacker RC-Para SET "RC-FREE"
© 2014 Hacker Motor GmbH
Hacker A30-28S
Hacker X40-SB-Pro
APC –E 10x5
250 cm
ca. 200 cm
Aramid gespleißt / aramid spliced
1,2 – 1,7 kg
Seite / page 6
