Installation
Basically, all connections are protected against external interference.
NOTICE
Choose a place of operation that excludes inductive or capacitive interfer-
ence influences on the incremental encoder. When mounting the system
keep a maximum possible distance from lines loaded with interference. If
necessary, provide additional installations including screening shields or
metallized housings.
Admissible power input
Supply for the incremental encoder shall be sized sufficiently. The volt-
NOTICE
age values are a function of the device design and can be referred to in the
technical data in chapter 8.
Connection type
• E1: open cable end
Assignment IG06: output circuit PP, OC
Assignment IG07: output circuit PP, PN
Signal
GND
channel A
channel B
channel 0/I
+UB
Assignment IG07: output circuit OP, ON (output signals AXX, AX0, AXI,
ABX)
Signal
GND
channel A
channel B; 0 white
+UB
channel /A
channel /B; I blue
