Risk of self-intervention and misuse
Self-interventions and misuse hide unpredictable risks and cause expiration of
warranty.
>> Do not modify or alter either the product or the accessories!
Risk of material damage by inappropriate ambient conditions
Incorrect ambient conditions can damage things.
>> Avoid extreme conditions, such as extreme heat, coldness, humidity or
direct exposure to the sun, as well as vibrations and mechanical pressu-
re.
>> Keep enough space around product and to the whole system to ensure
proper ventilation and mobility.
The included mounting material is only suitable for mounting on massive stone
or concrete walls.
>> For other wall types use suitable mounting material.
>> Check the stability of the system periodically after installation.
1.2

User Groups

Caused to different risk levels and hazard potentials some working steps only
may be done by trained specialists.
Working step User Group
Installing, Un- Consumers and users with basical mechanical knowledge
installing, Care, can do this work.
Storage, Trans- >> Protect children and people with mental and motoral
port, Disposal impairments from using the product!
Maintenance, Trained specialists only
Repairing >> special safety measures, knowledge and tools are nec-
essary!
Tab. 10: User Groups
1.3

Warning Levels

Warnings against hazards that will result directly in serious injuries or death
in case of non-observance.
Warnings against hazards that may result in serious injuries or death in case
of nonobservance.
Warnings against hazards that may result in injuries in case of non-obser-
vance.
18
63494+63495_V4.indd 18-19
Warnings against hazards that may result in material damage in case of
non-observance.

2 Description and Function

Your wall mount is made for mounting your flat screen at stable, vertical walls.
The compact and slim design supports individual, space-saving mounting. It is
tiltable but not swivelable.
2.1

Scope of Delivery

Part Figure
Wall mounting
Wall mount 63494
or
Wall mount 63495
Wall screw 6.3x55
Concrete anchor
Spacer D6
Flat screen mounting
Adapter bracket 63494
left
or
Adapter bracket 63495
left
Symbol Amount
A 1
W-A
63494:
each
4
W-B
63495:
each
6
W-C
B 1
19
