Wir regeln das.
5.3
Datenpunktliste
Register
Access
dec
hex
Trip value configuration (Register 1 to 100)
1
0x0001
R/W
9
0x0009
R/W
13
0x000D
R/W
14
0x000E
R/W
15
0x000F
R/W
16
0x0010
R/W
17
0x0011
R/W
18
0x0012
R/W
19
0x0013
R/W
Reset configuration (Registers 101 to 200)
101
0x0065
R/W
102
0x0066
R/W
107
0x006B
R/W
108
0x006C
R/W
Seite 32
Unit
Values
A
*
ms
40 to *
A
0 to 30
ms
500
to
2000
Step:100
ms
500
to
2000
Step:500
pulse
1 to 10
pulse
1 to 10
ON/OF
0 or 1
F
ON/OF
0 or 1
F
Min
0
to
2160
A
2 to 50
Sec
5
to
64799
Sec
5
to
64799
Description
Trip current short-circuit: all phases / single phase
indicator
On reading: The register returns the actual trip
current. In normal mode it returns the fixed trip
value.
In automatic mode it returns the calculated trip
current in A.
On writing: Switches off automatic adjustment of
trip current (if available) and sets a fixed trip value.
Writing 0 = switch off short-circuit detection
For EOR-1D: only values between 20 and 2500A in
steps 10A are allowed
Response time for short-circuit
For EOR-1D: only values between 20 and 3000ms in
steps of 20ms are allowed
Pulse locating: Minimum current deviation
0= OFF (added in Version 28)
Pulse locating: Switch on time of the detuning
Pulse locating: Switch off time of the detuning
Pulse locating: Pulse window (observation window)
Pulse locating: Minimum successfully detected
pulses in observation window
Voltage detection by LRM Interface
Directional fault indication (earth-fault and short-
circuit)
Reset time
Reset by recovering operating current on conductor
L1
2 = disabled / 3 to 50A = enabled
Short-circuit reset time
Earth-fault reset time
Modbus Protokoll
