7. Connection and Control Elements

2
3
4
5
6
1 Safety eyelet
2 Fog exit
3 DMX 3PIN IN connection
4 DMX 3PIN OUT connection
5 DMX 5PIN IN connection
6 DMX 5PIN OUT connection
7 Fill level display
8 POWER switch
9 Mains Connection
1
7
8
10
9
11
FUNCTION
12
16 17
10 Display
11 FUNCTION button
12 HAZE/FOG switch
13 button
14 button
15 button
16 TIMER button
17 VOLUME PUMP/FAN button
13
14
15
VOLUME
TIMER
PUMP/FAN
