2.3 Connecting with a remote monitor

Connect the extension cord V-KMVL-x or KMC-x (x = length in meter) with the
interface Monitor remote
Connect the other side of the extension cord with the remote monitor (or with
the connecting cable of your monitor).
3

Interface - Illustration

Basiclly the VS-2
illustration shows, what kind of interfaces exist:
„CPU"-side
1
Connecting video amplifying
power supply regulator
„monitor"-side
4
Interface
local monitor
of the VS-2
plus
consists of a PC side an a monitor side. The following
2 3
Interface
VGAin
Interface
remote monitor
page 5
Operation Instructions Video-Splitter 2
plus
.
5
