Connection and operation
Read and follow all instructions included in the user manual for each device
to be connected.
Turn off all devices to be connected and disconnect their mains plug from
the wall socket.
When choosing a cable, please note that there are different types of HDMI cables.
In case of doubt, consult a professional for further information.
The product supports 3D playback.
4K x 2K or 3D playback requires a playback device and an output device that
support these standards.
Use a high-speed HDMI cable for playback of 3D signals with a bandwidth
of >225 MHz or with a resolution of 4K x 2K.
• If needed, attach the provided rubber feet to the bottom of the device.
• Place the product on a stable, flat and horizontal surface.
• Connect a playback device (e.g. Blu-ray player) to the HDMI input.
You may also connect an MHL-compatible mobile device to the HDMI input using
a suitable cable.
• Connect a TV or monitor to the HDMI output.
• Connect a sound system to the RCA output.
• Connect a sound system to the TOSLINK output.
• Connect the low voltage plug of the power adapter to the power connection.
• Connect the power adapter to a suitable household power outlet.
• Connect the connected devices to the power supply. Then turn on all connected devices and
start playback. If necessary, select the proper input on the TV/monitor/audio amplifier.
• Use the slide switch to select the audio output mode.
Refer to the chapter "Audio output mode" below.
• Press the ARC button to activate/deactivate the ARC function.
ARC = Audio Return Channel
Using ARC, you can connect a game console to the TV and transfer the audio
signal to an amplifier via this product.
The TV must support the ARC function.
Audio output mode
Audio Active outputs
mode (simultaneous)
ADV HDMI
2CH HDMI, TOSLINK, RCA
5.1CH HDMI, TOSLINK
LED signals
LED Signal
PWR Indicating that the product is switched on.
ARC Indicating that the ARC function is activated.
HDMI OUT Indicating that a signal is rendered via HDMI output.

Troubleshooting

Problem Solution
The terminal devices do not If the power LED does not light up, the product is not
receive a signal. connected to the power supply. Make sure the product is
supplied with power.
If the problem continues to exist, contact an expert.
The power LED lights up, but Make sure all connected devices are turned on.
the terminal devices do not
Check all connections. All ports must be connected
receive a signal.
properly.
The LED indicator of the HDMI Check the position of the slide switch for the audio
signal lights up, but the terminal output mode. The audio formats must be compatible and
devices do not receive a signal the outputs used must be operated. (Refer to chapter
or only receive a partial signal. "Audio output mode".)
Required audio format
DTS-HD, Dolby True-HD, LPCM 5.1, LPCM 7.1
LPCM 2.0
Dolby AC-3, DTS 5.1
Maintenance and cleaning
• Before cleaning, disconnect the product from the connected devices and unplug it from the
power outlet.
• There are no components located inside the product you need to maintain. Never open/
dismantle the product.
• Under no circumstances use aggressive cleanings agents, cleaning alcohol or other chemical
solutions since these can penetrate the housing or impair functionality.
• To clean the product, a dry, soft and clean cloth is sufficient. Do not apply too much pressure
to the housing as this may cause scratch marks.
• You can easily remove dust using a long-haired, soft and clean brush.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household
waste.
At the end of its service life, dispose of the product in accordance with applicable
regulatory guidelines.
You thus fulfil your statutory obligations and contribute to the protection of the environment.
Technical data
a) HDMI audio extractor UHD
Input.................................................. HDMI
Outputs ............................................. HDMI, TOSLINK, RCA
Operating conditions ......................... -10 to +55°C, 10 – 90 % RH
Storage conditions ............................ -20 to +60°C, 5 – 95 % RH
Dimensions (W x H x D) ................... 84.5 x 21 x 61.8 mm
Weight .............................................. 135 g
b) Power adapter
Input voltage ..................................... 100 – 240 V/AC, 50/60 Hz
Output voltage/current ...................... 5 V/DC, 1 A
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represents the
technical status at the time of printing.
© Copyright 2015 by Conrad Electronic SE. V1_1215_02-ETS-Mkd
