Controller Functions; Memory Card (Optional) - PCE Instruments UA964801 Betriebshandbuch

8

Controller Functions

8.1

Memory Card (optional)

Parameters and setpoint values can be duplicated from one controller to another
using the Memory card.
2 modes are available:
1. With the controller connected to the power supply::
Insert memory card when the controller is off. On activation the LCD visualizes
Load data and
values are saved in the memory card. If not, you must update the memory card).
Pressing Load data
keeps the old values.
2. With the controller not connected to the power supply:
The memory card is equipped with an internal battery with an autonomy of about
1000 uses (2032 button battery, replaceable).
Insert the memory card and press the programming button. When writing the
parameters, led turns red and on completing the procedure it changes to green. It
is possible to repeat the procedure without any particular attention.
NB: it is not possible to transfer the parameters of a device to one with different
code: the LED lights red.
Updating Memory Card.
To update the memory card values, follow the procedure described on
first mode, pressing
Enter configuration and change at least one parameter. Exit configuration.
Changes are stored automatically.
Esc in correspondence of the relative keys (only if the correct
the controller loads the new values. Pressing
Esc so as not to load the parameters on controller.
Esc the device
User manual - UA964801
63
