Adjustments
Lateral Shift
10
Slide the TV side to side.
Make sure your TV is locked to wall
plate
(STEP 3-3).
10
Dimensions
( in. [mm] )
15.91 404.0
17.75 450.9
Level
Loosen
Tighten
Remove the TV.
Loosen both screws
level, then retighten the screws
(STEP 2-3
or 2-2
A
16.00 406.4
2.95 75.0
14
14
Loosen
Tighten
, adjust the
14
).
B
0.20
5.1
0.34
8.8
Remove the TV
17
Disconnect your cables.
Unlock wall plate
(STEP 1-3).
10
Lift the TV up and away.
1.12 28.6
1.5°
1.5°
2.77
70.3
LEVELING
0.98
1.10
25.0
27.9
10
5°
OPTIONAL
TILT
3.40
86.4
LATERAL SHIFT
