1 Console
2 Screw M8*P1.25*20L
3 Bushing Ø38.1 PA Black
4 Upper connected wire
6 Upright
7 Frame
8
C2 Roller
9 Screw M10*90L
10 Nylon nut M10
11
Elastic rope
12 Roller
14 Screw M5*12L
18
Screw M6*12L
19 Fixing plate
20 Screw M8*P1.25*16L
21
Block (Black)
22 Fixing plate
23 Screw M8*P1.25*60L
24 Nylon nut M8*7T
26 C2 Bushing
27 Bearing 6000 2ZZ
28 Roller
29 U shape holder
30 Screw M8*P1.25*55L
31 Screw M6*P1.0*35L
32 C2 inner bushing Ø6*Ø8*20L
33 Flat washer Ø6.5*Ø13*1T
34 Nylon nut M6*5.5T
35 Water tank holder
36
Pull rope
37 Handlebar
38 Screw M5*10L
39
Lower pedal cover
40 Pedal adjust pad
41 Pedal strap 750*25*1T
42
Pedal fixing plate
43 EVA pad
44 End cap
45
End cap
46 Lower cover of water tank
47 Washer
26 R-21
WATER ROWER
QTY
1 48 Upper cover of water tank
4
49 Block
2 50 Screw M4*P0.7*16
1 51 Flat washer φ4.5*φ11*1.5T
1 52
Nylon nut M4
1 53 O-Washer φ9*φ5*φ2
6 54 Screw M6*20L
1 55
CH20 Plate
1 56 Bolt φ6*60
1 57 Shaft
2 58
Wave washer Ø20.5*Ø30*0.3T
2 59 U80 Bushing
8 60 Pull wheel
1 61
Strong magnet Ø15*4
4 62 Spring
4 63 Screw M5*10L
1 64 Plate
3 65 Locked block
9
66 P106 Insert S41*93.5L
12 67 One way ratchet HF2016
8 68 Bearing 6804 2RS
4
70 Reinforced plate
1 71 Screw M6*12
1 72 Lower bearing housing
2
73 CH2O Upper bearing housing
2 74 Bearing 6004 2RS
4 75 C-shape clasp Ø18.5*Ø22.5*1T
3 76
P106 Sensor bracket
1 77 Lower sensor of wire
1 78 Screw M5*10L
1 79 CH2O Plate φ100*2T
18 80 CH2O Bearing house
P106 gasket φ90*φ50*5.3T
2 81
2 82 TC φ32*φ22*7
2 83 Semicircle cover
2 84 Screw M5*16L
2 85
Screw M8*P1.25*50L
4 86 Flat washer Ø8*Ø16*2T
1 87 Front stabilizer
1 88
Front Stabilizer end cap (L)
1 89 Screw ST4.8*12L
QTY
1 90 Screw ST3. 9 *50L
91 Inner cover
1
12 92 Front Stabilizer end cap (R)
12 93 Block
94 Front holder
12
2 95 Cover sheath
96
8 Round cover
97 Upper cover
1
2 98 Lower cover
99
1 Screw ST3.5*16L
100 Screw 3/16"*3/4"
1
2 101 Handlebar bracket
102
1 Fixing plate
103 Seat
3
1 104 Slider cover
105
1 Flat washer Ø6.5*Ø16*2T
1 106 Slider
1 107 Screw M8*30L
108 C2 Roller bushing Ø16*Ø8.2*18.8L
1
1 109 Lower Roller
2 110 Flat washer Ø8*Ø14*1T
111 Upper Roller
1
6 112 Screw M8*P1.25*16L
1 113 P500 Rail 100*54*1300L
114 Support tube 40*80*2T*1296L (90°,45°) pipe
1
2 115 Light-strips
2 116 Upper sensor wires
117 Lights cover
1
2 118 Screw M5*16L
119
1 Buffering pad
120 Nut M6
1
1 121 Screw M6*75L
122
1 End cap for rail
123 Lower supporting base cover
1
1 124 Rear stabilizer
125
6 Upper supporting base cover
126 Rear stabilizer end cap
2
19 127 CH2O Water absorption
128
1 Harpoon wrench 13.14. 1 5
129 Hexagon wrench 6mm*30mml*84mml
1
8 130 Screw M6*20L
QTY
4 134 Screw M8*P1.25*20L
2
137 Nylon nut M10
1 138 Screw M6*16L
1 139 Lighting PCB
1 140
Screw M5*12L
1 143 Spring washer Ø8.1*2.4T
2 145 Middle lights connected wire
1 147
Dongle
1 148 DC wires
4 149 Screw
4 150
Adaptor
1
1
1
2
4
1
6
6
2
6
4
10
1
1
1
2
1
7
4
4
4
1
1
1
1
2
1
1
1
2
