LEXUS PARKING AID 800
INSTALLATION INSTRUCTIONS
RX300/350/400h RHD
Model year
Vehicle code
Part number
Weight
Manual reference number: A A I I M M 0 0 0 0 0 0 3 3 1 1 8 8 - - 2 2
2003
**U3*R-AW*GKW
PZ464-K0425-00
Main Kit
1. 9 kg
Sensor Kit
0.3 kg
