Wiring Diagram - Respekta KG176W-37 Bedienungs- & Installationsanleitung

3.2

Wiring diagram

2 2
3 3
3.1 3.1
4 4 5 5
1 - Control panel
2 - Display
3 - Compressor
3.1 - Fuse
4 - Switch
5 - Plug
6 - Heating element
7 - Temperature sensor
en-16
1 1
6 6 7 7
Fig. 3.2
