LABELS & PICTOGRAMS
Read all of manual to become familiar with this vehicle. Pay attention to all NOTICES, CAUTIONS, WARNINGS and DANGERS.
B
DO NOT TOW MORE THAN 3 VEHICLES MAX 12 mph (19 kph) TOWING 1 VEHICLE
DO NOT DRIVE IN REVERSE WHEN TOWING VEHICLES
NO PASSENGERS IN TOWED VEHICLES
DO NOT TOW VEHICLES OVER UNEVEN TERRAIN
READ THE
MANUAL
REPLACEMENT
AVAILABLE AT
www.ezgo.com
WARNING: ATTACH TOW BAR BEFORE
TURNING KEY SWITCH TO 'TOW'
KEEP READ THE
HANDS MANUAL
OUT REPLACEMENT
AVAILABLE AT
www.ezgo.com
WARNING CHOCK
READ THE THE
MANUAL WHEELS
MOVE THE
VEHICLE
Page xvi
10% MAX SLOPE FOR TOWING VEHICLES
MAX
10%
WARNING
WARNING
ENGAGE
DO NOT
LOCKING
DRIVE
COLLAR
FAST
ON
N F
R
O
OFF
608769
TO REDUCE POSSIBILITY OF
BATTERY EXPLOSION TURN
KEY TO 'OFF' BEFORE
DISCONNECTING OR CONNECTING
BATTERY WIRES
UNPLUG
1 FROM 2
AND
3 FROM 4
4
3
1
2
1
CHOCK
THE
WHEELS
MAX 5 mph (8 kph) TOWING 2 or 3 VEHICLES
612214
MAX
12 mph
(19 kph)
MAX
+
5 mph
(8 kph)
WARNING INSPECT TOW BAR
SYSTEM EVERY 30 DAYS
608769
PLUG
1 INTO 3
4
1
3
2
4
3
2
610990
610990
PLUG
1 INTO 2
AND
3 INTO 4
Owner's Guide
TOW BAR OPERATION
* PULL LOCKING COLLAR AWAY
FROM LATCH AND PRESS ON
LATCH TAB TO OPEN
* PLACE LATCH OVER FRONT
TOWING BRACKET
* CLOSE LATCH AND MOVE
LOCKING COLLAR UNDER
LATCH TAB
* DO NOT TOW MORE THAN
3 VEHICLES
* 12 mph (19 kph) MAX SPEED
612214
TOWING 1 VEHICLE
* DO NOT DRIVE IN REVERSE
WHEN TOWING VEHICLES
* NO PASSENGERS IN TOWED
VEHICLES
* DO NOT TOW VEHICLES OVER
UNEVEN TERRAIN 10% MAXIMUM
SLOPE FOR TOWING VEHICLES
IF THE WARNING
VEHICLE READ THE
WILL NOT MANUAL
MOVE
