2. Put the diesel heater on the frame and
align the 4 holes in the handle (1) with
the 4 holes in the frame.
3. Fit the frame with the wheels and handle
on the tank with screws (2), spring
washers (3), flat washers (4) and nuts (6).
USE

INTENDED USE

The diesel heater is intended for use in open
areas outdoors or in well-ventilated spaces
indoors. When used indoors there must be
permanent ventilation openings of at least
25 cm²/kW, evenly spaced over the height of the
walls, with a minimum total area of 250 cm².
INSTRUCTIONS FOR USE
IMPORTANT:
Place the diesel heater on a flat, stable, level,
non-flammable surface.
Start
1. Fill the fuel tank with fresh fuel. Only use
diesel oil or paraffin. The fuel indicator
over the tank shows the fuel level.
2. Insert the plug into an earthed power
socket.
3. When the above steps have been
completed, the left display window shows
"--" and the right display window shows
the ambient temperature.
4. Put the On/Off switch in the ON position (I).
5. The default temperature setting is
20°C. If the thermostat dial is set to a
higher temperature than the ambient
temperature, turn the thermostat dial
to the required temperature setting. The
electrodes start sparking and the product
starts after 7 seconds.
6. If the thermostat dial is set to a
lower temperature than the ambient
temperature, turn the thermostat dial
to the required temperature setting. The
electrodes start sparking and the heater
starts after 7 seconds.
Cold start
At low ambient temperature, put a finger
over the air hole (12) when lighting to make it
easier to start.
FIG. 2
Manual reset/restart
1. If the diesel heater is in locked mode,
check and remove the cause of lock-out
before restarting it.
2. Reset by turning the On/Off switch to O
and then back to I.
NOTE:
Turning the thermostat dial will not reset the
diesel heater.
Shut down
1. Put the On/Off switch in the OFF position (O).
2. Remove the plug from the power socket if
the diesel heater is not going to be used
for some time.
NOTE:
Never remove the plug from the power
socket while the diesel heater is running.
MALFUNCTION
In the event of malfunction (flame failure,
reduced air flow, poor combustion, etc.) the
diesel heater shuts down and the indicator
light starts flashing. The code for locked mode
is displayed on the screen.
