Bosch Rexroth AG
Montage
Gewinde
M4
Tab.10-1: Montagemomente
5,5
①
Bohrloch für die Montagebolzen, Bohrungsdurchmesser 4,5 mm
②
Montageausschnitt
Abb.10-1: Montageausschnitt VAK 10.1
5,5
129
①
Bohrloch für die Montagebolzen, Bohrungsdurchmesser 4,5 mm
②
Montageausschnitt
Abb.10-2: Montageausschnitt VAK 40.1
12/21
Rexroth IndraControl VAK 10.1, VAK 40.1 Einschubtastatur
Montagemoment
1,4 Nm
167,5
129
387
DOK-SUPPL*-VAK*X0.1***-IT01-DE-P
324
2
335
376
2
1
1
