20 | English
When working with the machine, always
hold it firmly with both hands and provide
for a secure stance. The power tool is guided
more secure with both hands.
Secure the workpiece. A workpiece clamped
with clamping devices or in a vice is held
more secure than by hand.
Keep your workplace clean. Blends of mate-
rials are particularly dangerous. Dust from
light alloys can burn or explode.
Always wait until the machine has come to
a complete stop before placing it down. The
tool insert can jam and lead to loss of control
over the power tool.
Avoid unintentional switching on. Ensure
the On/Off switch is in the off position be-
fore inserting battery pack. Carrying the
power tool with your finger on the On/Off
switch or inserting the battery pack into
power tools that have the switch on invites
accidents.
Do not open the battery. Danger of short-
circuiting.
Protect the battery against heat, e. g., al-
so against continuous sun irradiation
and fire. There is danger of explosion.
In case of damage and improper use of the
battery, vapours may be emitted. Provide
for fresh air and seek medical help in case
of complaints. The vapours can irritate the
respiratory system.
When the battery is defective, liquid can es-
cape and come into contact with adjacent
components. Check any parts concerned.
Clean such parts or replace them, if required.
Use the battery only in conjunction with
your Bosch power tool. This measure alone
protects the battery against dangerous over-
load.

Functional Description

Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
1 619 929 797 | (3.2.09)
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.

Intended Use

The machine is intended for hammer drilling in
concrete, brick and stone. It is also suitable for
drilling without impact in wood, metal, ceramic
and plastic. Machines with electronic control
and right/left rotation are also suitable for
screwdriving.

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Depth stop
2 SDS-plus tool holder
3 Dust protection cap
4 Locking sleeve
5 Vibration damper
6 Rotational direction switch
7 On/Off switch
8 Selector switch for drilling/hammer drilling
9 Button for depth stop adjustment
10 Wing bolt for adjustment of auxiliary handle
11 Battery*
12 Battery unlocking button
13 Temperature control indicator
14 Battery charge-control indicator
15 Button for charge-control indicator
16 Auxiliary handle
17 Securing screw for key type drill chuck*
18 Key type drill chuck*
19 SDS-plus adapter shank for drill chuck*
20 Extraction sleeve of the dust extraction
attachment*
21 Clamping screw for the dust extraction
attachment*
22 Depth stop of the dust extraction
attachment*
23 Telescopic pipe of the dust extraction
attachment*
