Important! It is prohibited to use the tool to
chop material for composting because of the
potential danger to persons and property.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user/operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Speed n : ............................................... 950 rpm
0
Cutting width of the grass cutter: .............. 70 mm
Cutting width of the shrub shears ........... 100 mm
Cutting thickness of the shrub shears ........ 8 mm
Running time max.: ...................................60 min
Battery pack: ............... Li-Ion / 3,6 V d. c. / 1.5 Ah
Charging time: ............................................. 3-5 h
Protection class: ................................................III
L sound pressure level: ............................ 62 dB
pA
K uncertainty ............................................. 2 dB
pA
L sound power level: ............................... 82 dB
WA
K uncertainty ............................................. 2 dB
WA
Vibration max. a : .................................... 5.5m/s
h
K uncertainty ........................................... 1.5m/s
Weight: .......................................................0,5 kg
Sound pressure level at the operator's ear .. 77 dB
Battery charger
Mains voltage................................. 230 V ~ 50 Hz
Output
Rated voltage ............................................ 5 V DC
Rated current: .......................................... 300 mA
•
The vibration emission level has been measu-
red in accordance with a set of standardized
criteria and can be used to compare one po-
wer tool with another.
•
The specified emission level can also be
used to make an initial assessment of the ex-
posure to vibrations.
Anl_GC_CG_3_6_Li_WT_SPK9.indb 13 Anl_GC_CG_3_6_Li_WT_SPK9.indb 13
GB
Warning!
The vibration emission level may vary from the le-
vel specifi ed during actual use, depending on the
way in which the power tool is used.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
2

5. Before starting the equipment

2
5.1 Charging the battery pack (Figure 1, 3)
•
Connect the charger to the charging station
(Figure 3).
•
Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Plug the battery charger in a socket-
outlet. The red LED (Figure 3/Item 1) comes
on to indicate that charging voltage is availab-
le.
•
The battery pack is being charged. An empty
battery pack requires a maximum charging
period of 3 to 5 hours. The temperature of the
battery pack may rise slightly during the char-
ging operation. This is normal.
•
As soon as battery pack is fully charged, the
red LED (Fig. 3/Item 1) extinguishes
If the rechargeable battery fails to charge, check
whether there is voltage at the socket outlet.
- 13 -
