Miele APCL WOD Umbau- Und Montageanweisung Seite 6

M.-Nr. 11477230
en
Fitting instructions for APCL WOD plinth
Reason: Fitting a washing machine or tumble dryer on a plinth enables a more ergonomic height to be achieved.
Included parts
No. Mat. no. Designation
1 Plinth
4 20 l media canister (APCL022, APCL024 only)
6 20 l media canister (APCL023 only)
2 Clamp
4 Galvanised washer B6.4
2 Hexagonal bolt M6 x 30
4 Nut M6
2 Clamping plate
4 Raised-head screw CEM 6 x 12
2 Hexagonal bolt M6 x 20
Danger due to incorrectly carried out service and repair work
WARNING

Danger due to incorrectly carried out service and repair work
There is a risk of serious damage, injury and even death if service and repair work is carried out incorrectly.
A
Service and repair work should only be carried out by a suitably qualified electrician with specialist training,
knowledge and experience.
A
All appropriate safety regulations must be taken into account.
A
First read the Technical Service Documentation (TSD), then commence work.
Measures to be carried out before commencing any service work
- Carry out appropriate electrical safety checks.
- Disconnect all machine utility connections in accordance with the operating instructions.
Measures to be carried out after service work has been completed
- Carry out appropriate electrical safety checks.
- Check the appliance for correct operation.
Risk of injury due to sharp edges
WARNING

Some components may have sharp edges.
Risk of injury due to sharp edges
A
Protective gloves should be worn and the edge protection (mat. no. 05057680) should be used.
Diese Unterlagen dürfen ohne unsere Genehmigung weder vervielfältigt noch Dritten zugänglich gemacht werden. Eigentumsrechte vorbehalten.
Umbau- und Montageanweisung
6 von 55
18.03.2021
