4
2.2 LCD screen (see P2)
Channel number.
Changes from 1 to 8 as selected by the user.
CTCSS code.
Changes from 1 to 38 as selected by the user.
Displays the battery change level.
Displayed when the stop watch function is activated.
TX
Displayed when transmitting a signal.
RX
Displayed when receiving a signal.
DCM
Displayed when the dual watch function is turned on.
Displayed when the Digital Code System is turned
DCS
on.
VOX
Displayed when the VOX feature is enabled.
SC
Displays when the PMR is scanning all channels.
Displayed when the key lock feature is activated.
Displays the current speaker volume level.
3

INSTALLATION

3.1 Removing the belt clip
Pull the belt clip latch forward (away from the PMR).
While pulling the belt clip latch, push up the belt clip as shown in
Fig. 1.
Meaning
