HPS50 PersonalScope
Maximum sample rate
Input amplifier bandwidth (-3dB)
Input impedance
Maximum input voltage
Input coupling
Vertical resolution
Trigger modes
Trigger level
LCD Graphics
Signal storage
dBm measurement (0dBm= 0.775V in 600ohm)
dBV measurements (0dBV= 1V)
True-rms measurement
Peak to peak AC sensitivity (sinewave ref.)
Timebase range in 32 steps
Input sensitivity range in 12 steps
Probe calibration output
Supply voltage
Batteries (included)
Battery current (average)
Operating temperature
Fysical characteristics
TM
40MS/s for repetitive signals (5MS/s for single shot events)
From 5MHz at 5mV/div to 12MHz at 50mV, 1V & 20V /div
1Mohm // 20pF (standard oscilloscope probe)
100Vpeak (AC + DC), 200Vpeak-peak (AC only)
DC, AC and GND (GND for auto zero reference)
+
8 bit
1bit linearity
Run, Normal, Once, Roll mode for 1s/div and slower timebase
Adjustable in 8 steps
112 x 192 pixels with LED backlight
256 samples with 2 memories, max. 179 samples visible (256 using X shift)
From -73dB tot +40dB (up to 60dB with X10 probe)
From -75dB tot +38dB (up to 58dB with X10 probe)
From 0.1mV to 80V (up to 400Vrms with X10 probe) 2.5% accuracy
0.1mV to 160V (1mV to 1000V with x10 probe) 2% accuracy
50ns to 1hour / division
5mV to 20V/division at X1- 50mV to 200V/div at X10
Approx. 2KHz / 4.5Vpp
12VDC/500mA regulated adapter (included)
Lithium Ion battery 7,4V/1050mAh (order -LI-ION7V4)
190mA low intensity (backlight) - 220mA high intensity (backlight) - 600µA stand-
by
0 to 50°C (32 to 122°F)
Dim: 105x220x35mm (4.13x7.95x1.38") Weight 450g (16oz.) ex. Batteries
Specifications
+
0.5dB accuracy
+
0.5dB accuracy
71
