Armrests normally do not distinguish sides
unless labeled otherwise.
For models with armrest pre-assembled,
please skip this step.
Remove the pre-assembled bolts and washers (
1
( ) between the armrest mounting bar (
place, then insert and tighten all 4 bolts (
repeat on the other side.
Use the hex key to remove the pre-assembled
bolts and washers from the backrest.
Remove the protective foam covers from the brackets of the seat base. Then position
the backrest carefully between the brackets. Insert and attach the 4 bolts (2 on each
side) you removed in step 5 by hand first. Then use the hex key to tighten them. Start
with the two bolts on the top of each side, then the bottom two.
6
1 3
& ). Place the 4 large washers
2
) and the seat base. Hold the armrest in
3
). Use the hex key to tighten them all, and
