Variez les positions et l'orientation des enceintes avant de les fixer définitivement
pour déterminer leur position idéale dans le local d'écoute.
Exemple de positionnement :
au moins 50 cm
au moins 50 cm
18
au moins 50 cm
auditeur
Functional description
The loudspeakers are designed according to the two-way bass reflex principle.
The cabinet is reinforced to avoid resonance.
A 165 mm driver with phase plug radiates the bass- and mid-range, a 25 mm dome
is used for the treble range.
The speaker cables are connected by means of screw terminals to which banana
plugs may also be attached.
Putting into operation
You must read these operating instructions including all safety
instructions in full and carefully in order to put the loudspeakers
properly into operation!
How to set up the loudspeakers
Do not place the loudspeakers close to monitors/screens, such
as for example TV screens or computer monitors. Otherwise you
risk that the magnetic fields of the loudspeakers distort the image.
In order to change the frames, the frame
dowels supplied must be integrated in
the additionally supplied covering frame.
In order to achieve the best possible sound reproduction, please try to implement
the following instructions for the installation in the listener room as far as possible:
• Place the loudspeaker so that the listener's seat has the same distance to both
loudspeakers (equilateral triangle).
• In rectangular rooms the loudspeakers should be placed along one of the short
walls, if possible.
• The tweeters should be approximately at ears' height. For this purpose loudspeak-
er stands are very useful, which are placed on the floor thus raising the tweeters to
ears' height.
• If possible, the speakers should stand alone (approx. 50 cm away from each wall).
Place a dowel in a predrilled hole in the
frame; put one of the sleeves enclosed
on it and carefully beat the dowel with a
small hammer into the drillhole.
Then remove the sleeves and press the
covering frame in the dowels of the
loudspeaker.
11
