Radio gateway
3 Lock
4 Strain relief fastenings
5 Cable entries
6 Back box
▷ Radio gateway, battery pack, fixing screws, and cable tie are at hand.
▷ You have the device location plan at hand.
▷ The connection cable has a conductor cross-section of 0.2...1.5 mm².
▷ The lines to the installation location are installed.
▷ Two fixing screws (Ø max. 3.6 mm) are at hand.
1. Determine the installation location:
- The housing must be positioned in accordance with the planning
specifications (make sure there is a wide radio range and that the
housing can be accessed easily).
- Make sure there is enough space for you to open the housing
cover easily.
- The housing may be installed in any appropriate position.
2. Remove the adhesive label bearing the serial number from the
product label and use it to mark the installation location on the
device location plan.
3. In the back box (6), break out the plastic for the cable entry:
- Openings in the supporting surface for flush-mounted cables (5a)
- Openings in the narrow side for surface-mounted cables (5b)
4. Insert the cables into the back box (6).
5. Mount the back box (6), without the battery pack, on a flat surface
using two screws (Ø max. 3.6 mm) at the mounting points. One
screw at the mounting point is sufficient for fixing in housing.
6. Fasten the cable using a cable tie as strain relief (4).
