Pepperl+Fuchs VBG-ENX-K20-D Montageanweisung Seite 12

1.7 Quick Setup / Quick setup / Quick Setup / Setup veloce / Setup rápido
config error
. 5
1xOK
↓
ETHERNET
QUICK SETUP
SETUP
IO + PARAM. TEST
OK
WARNING:
OUTPUTS MAY BE
RESET
OK ↓
STORE AS-I
CONFIGURATION
STORE +RUN
STORE +PRJ MODE
12
Zumutbare Änderungen aufgrund technischer Verbesserungen vorbehalten.
Pepperl+Fuchs GmbH · 68301 Mannheim · Telefon (06 21) 7 76-11 11 · Telefax (06 21) 7 76 27-11 11
AS-i 3.0 EtherNet/IP+Modbus TCP-Gateway
LCD
LCD
LCD
LCD
Montageanweisung // Installation Instructions
OK
STORE AS-I
CONFIGURATION
OK
STORE +PRJ MODE
2x ESC
.
CONFIGURATION OK
HOST ERROR
NO CONNECTION
© Pepperl+Fuchs, Printed in Germany
Internet http://www.pepperl-fuchs.com
LCD
LCD
LCD
