16 | English
Typically the A-weighted noise levels of the product are:
– Sound pressure level
– Sound power level
– Uncertainty K
Vibration total values ah (triax vector sum) and uncertainty K determined according to EN 50636-2-100
– Vibration emission value a
h
– Uncertainty K
Assembly
Caution: Switch garden tool off and remove battery
u
from machine before adjusting or cleaning.
Mounting the nozzle (see figure B)
Slide the nozzle (5) onto the motor unit. Take care not to
pinch your fingers during assembly.
Inserting/Removing the Battery (see figure C)
Note: Using unsuitable batteries can lead to malfunctions or
damage the machine.
Insert the charged battery (6). Ensure the battery is inserted
correctly.
To remove the battery (6) from the machine, press the bat-
tery unlocking button and pull the battery out.
Switching on
Before any work on the garden product itself (e. g.
u
maintenance, tool change, etc.) as well as during
transport and storage, remove the battery from the
garden product. There is danger of injury when uninten-
tionally actuating the On/Off switch.
The machine continues to blow for a few seconds after
u
being switched off. Allow the motor to stop rotating
before switching "on" again.
Do not rapidly switch off and on.
Charging the Battery
Observe the correct mains voltage! The voltage of the
u
power supply must correspond with the data given on
the nameplate of the battery charger. Battery char-
gers marked with 230 V can also be operated with
220 V.
The battery is equipped with temperature monitoring that al-
lows charging only in the temperature range between 0 °C
and 45 °C. In this manner, a high battery service life is
achieved.
Note: The battery is supplied partially charged. To ensure
full battery capacity, completely charge the battery in the
battery charger before using for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging procedure
does not damage the battery.
F 016 L81 393 | (05.02.2019)
dB(A)
dB(A)
dB
2
m/s
2
m/s
The "Electronic Cell Protection (ECP)" protects the lithium-
ion battery against deep discharging. When the battery is
discharged, the machine is switched off by means of a pro-
tective circuit: The garden product no longer operates.
Do not continue to press the On/Off switch after an auto-
matic shut-off of the machine. The battery can be dam-
aged.

Charging Procedure

The charging procedure starts as soon as the mains plug of
the charger is plugged into a socket outlet and the battery is
inserted onto the charger .
Due to the intelligent charging method, the charging condi-
tion of the battery is automatically detected and the battery
is charged with the optimum charging current, depending on
battery temperature and voltage.
This gives longer life to the battery and always leaves it fully
charged when kept in the charger for storage.
Meaning of the indication elements on the
charger (AL 3620 CV/AL 3640 CV/AL 36V-20)
Rapid-charging Procedure
The rapid-charging procedure is indicated by
flashing of the green battery charge indicator.
Indication element of the battery: During the
charging procedure, the three green LEDs light up one after
the other and briefly go out. The battery is fully charged
when the three green LEDs light up continuously. The three
LEDs go out again approx. 5 minutes after the battery has
been fully charged.
Note: The rapid-charging procedure is only possible when
the battery temperature is within the allowable charging
temperature range, see section "Technical Data".
Battery charged
Continuous lighting of the green LED indic-
ator indicates that the battery is fully charged.
Additionally, a signal tone sounds for approx.
2 seconds, which acoustically indicates that the battery is
fully charged.
Afterwards, the battery can be removed for immediate use.
When the battery is not inserted, continuous lighting of the
LED indicator indicates that the mains plug is inserted in the
socket outlet and that the battery charger is ready for opera-
tion.
3 600 HA0 4..
78
90
3.0
<2.5
1.5
