Document Shredder IPS018.s
Item no. 88 34 82
1.
Intended use
This product is designed for shredding paper, CDs and credit cards. The separate collection container allows
the separation of shredded CDs and credit cards from shredded paper. Use the product only in dry indoors.
Unauthorised conversion and/or modification of the device are inadmissible because of safety and approval
reasons (CE). Any usage other than described above is not permitted and can damage the product and lead to
associated risks such as short-circuit, fire, electric shock, etc. Please read the operating instructions thoroughly
and keep them for further reference.
2.
Content of delivery
•
Shredder
•
Operating instructions
3.
Safety instructions
We do not assume liability for resulting damages to property or personal injury if the
product has been abused in any way or damaged by improper use or failure to observe
these operating instructions. The warranty/ guarantee will then expire!
The icon with exclamation mark indicates important information in the operating
instructions. Carefully read the whole operating instructions before operating the device,
otherwise there is risk of danger.
Persons / Product
•
The product is not a toy and should be kept out of reach of children!
•
Do not reach into the feeder slot.
•
Do not insert paper pin, staples or any other metal parts into the feeder slot.
•
Keep long hair away from around the feeder slot.
•
Keep ties, scarves, loose clothing and long necklaces or bracelets away from the feeder slot.
•
Do not use spray bottles / cans in the immediate vicinity of the product.
•
The product must not be subjected to heavy mechanical stress.
•
The product must not be exposed it to extreme temperatures, direct sunlight, intense vibration, or
dampness.
•
Unplug the mains plug from the mains outlet before cleaning the product or storing it for a longer period.
•
Do not operate the device for longer than 2 minutes to avoid overheating the motor.
•
The product should not be connected immediately after it has been brought from an area of cold
temperature to an area of warm temperature. Condensed water might destroy the product. Wait until the
product stabilising to adapt to the new ambient temperature before use.
•
If there is reason to believe that safe operation is no longer possible, the device is to be taken out of
operation and secured against unintended operation. Safe operation is no longer possible if:
-
the device has sustained visible damages,
-
the device no longer works properly,
-
and the device was stored under unfavourable conditions for a long period of time,
-
the device was subject to considerable transport stress.
Miscellaneous
•
Servicing, adjustment or repair works must only be carried out by a specialist/ specialist workshop.
•
If any questions arise that are not answered in this operating instruction, contact our Technical Advisory
Service or other experts.
4.
Operating elements
5.
Initial operation
1.
Place the shredder on a level surface.
2.
Plug the mains plug into a mains socket.
Shredding paper
Do not insert more than 6 sheets of paper (size DIN A4 with a maximum grammage of
75 g/m
) into the insertion slot.
2
Do not shred adhesive notes or paper with remains of adhesive.
1.
Slide the selector switch to the right into the 'AUTO' position.
2.
Now, carefully insert the paper into the insertion slot. The paper will automatically be fed in and shredded.
Shredding CDs / credit cards
Version 04/12
1.
2.
3.
4.
5.
6.
Clearing paper jams
1.
2.
3.
6.
Problem
The cutting unit continuously
keeps on running in the 'AUTO'
position.
After shredding, there are still
pieces of paper remaining in the
cutting unit.
The automatic paper feed does
not work properly after having
used the cutting unit's 'REV'
mode.
The automatic feed stops,
however there is still paper in the
insertion slot.
The device does not work,
although no pieces of paper
remain in the feeder.
7.
8.
Operating voltage:
Max. power consumption:
Safety level:
Noise level:
Shredding speed:
Container volume:
Operating temperature:
Blade clearance:
Insertion slot width:
1. Selector switch
Dimensions (W x H x D):
Weight:
2. 'CLEAR' button
3. Credit card insertion slot
4. CD insertion slot
5. Paper insertion slot
6. Collection container
© 2012 by Conrad Electronic SE.
Shred only one CD or credit card at a time.
Place the small collection container in the guide rails under the CD/credit card insertion slot.
Slide the selection switch into the middle position, 'FWD CD/Card'. The motor is now permanently turned
on.
Next, carefully insert a single credit card into the credit card insertion slot. The credit card will be fed in
and shredded.
Bring the grey cap into the upright position to shred a CD.
Next, carefully insert a single CD into the CD insertion slot. The CD will be fed in and shredded.
When finished, slide the selector switch to the right, into the 'AUTO' position.
Slide the selector switch to the 'REV' position.
The cutting unit will now run in the reverse direction and push the jammed paper out again.
If pieces of paper remain in the cutting unit, press and hold the 'CLEAR' button. The remaining pieces will
now be shredded.
Troubleshooting
Cause
The paper container is full and
the paper from the cutting unit
cannot feed through.
The remaining pieces of paper
are stuck between blades.
Remaining pieces of paper block
the automatic feed.
The paper was inserted into the
insertion slot at an angle.
The paper is too soft, thin, damp
or creased.
The motor is overheated.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product according to the relevant statutory
regulations.
Technical data
230 V/AC, 50 Hz
0.9 A
3 (acc. to DIN 32757)
< 72 dB
7 sec per DIN A4 page
10 l (paper)
0.75 l (CD/credit card)
-10 ºC to +85 ºC
7 mm (paper)
40 mm (CD/credit card)
220 mm
280 x 286 x 146 mm
1.5 kg
These operating instructions are published by Conrad Electronic SE,
Klaus-Conrad-Straße 1, D-92240 Hirschau/Germany.
All rights including translation reserved. Reproduction by any method, e.g.
photocopy, microfilming, or the capture in electronic data processing systems
require the prior written approval by the editor. Reprinting, also in part, is prohibited.
The operating instructions reflect the current technical specifications at time of print.
We reserve the right to change the technical or physical specifications.
Solution
Unplug the mains plug and empty
the container.
Slide the selector switch into the
'REV' position or press and hold
the 'CLEAR' button.
Ensure the paper is straight as it
goes into the insertion slot.
Fold, dry or flatten the paper.
Leave the device to cool down
before putting it into operation
again.
V2_0412_02-SB
