Solar module
Item no. 11 04 43 (18 V/DC, 150 mA)
Item no. 11 04 54 (6 V/DC, 150 mA)
Item no. 11 04 55 (4 V/DC, 250 mA)
Item no. 11 04 56 (3 V/DC, 250 mA)
Item no. 11 06 44 (12 V/DC, 250 mA)
Item no. 11 06 82 (3 V/DC, 850 mA)
Item no. 11 06 83 (6 V/DC, 450 mA)
Item no. 11 06 84 (6 V/DC, 650 mA)
1.
Intended use
This polycrystalline solar module converts the radiant energy contained in light (usually sunlight) into electrical
energy. A range of different devices can be attached, using the screw connections of the solar module. This
requires wires and/or adaptor plugs (not included in delivery).
The compact solar module is suitable as a power source for outdoor activities. For example, you can charge
the built-in battery of an electrical appliance.
It can also be used as illustrative course material (e.g. at universities) to explain the functionality of solar
modules and to carry out experiments with it.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
cause hazards such as short circuiting, fire, electric shock etc. Read the instructions carefully and keep them.
Make this product available to third parties only together with its operating instructions.
2.
Delivery content
•
Solar module
•
Operating instructions
3.
Safety instructions
Read the operating instructions carefully and especially observe the safety information.
If you do not follow the safety instructions and information on proper handling in this
manual, we assume no liability for any resulting personal injury or damage to property.
Such cases will invalidate the warranty/guarantee.
Persons / Product
•
The solar module's performance can vary depending on weather conditions. Keep this in mind when
operating a device with this product.
•
Do not touch the terminal points during operation.
•
Use suitable extension cables and adaptor plugs approved for outside operation and use with a solar
module to connect the product to an electrical device. Do not use bare wires or other uninsulated objects
to connect the product.
•
Always ensure correct polarity when connecting a device.
•
Avoid direct contact with the surface. The surface is sensitive and can be easily scratched or destroyed
through contamination.
•
Solar modules may only be used in a temperate climate. The solar module is a device which is not secured
against explosions. Thus, it may not be installed in the vicinity of highly inflammable gases and vapours.
•
The solar module generates power as soon as it is exposed to light. A single module generates power below
the so-called low voltage barrier. However, multiple modules in parallel (summation of currents) or series
connection (summation of voltages) represent a potential risk.
•
If this solar module is used in a system consisting of multipe solar modules, all modules used must have the
same amperage. Only solar modules with identical amperage may be used when connected in series. Only
solar modules with identical voltage may be used when connected in parallel.
•
The device is not a toy. Keep it out of the reach of children and pets.
•
Do not leave packaging material lying around carelessly. These may become dangerous playing material
for children.
•
Protect the product from extreme temperatures, strong jolts, high humidity, moisture, flammable gases,
vapours and solvents.
•
Do not place the product under any mechanical stress.
•
If it is no longer possible to operate the product safely, take it out of operation and protect it from any
accidental use. Safe operation can no longer be guaranteed if the product:
-
is visibly damaged,
-
is no longer working properly,
-
has been stored for extended periods in poor ambient conditions or
-
has been subjected to any serious transport-related stresses.
•
Please handle the product carefully. Jolts, impacts or a fall even from a low height can damage the
product.
•
Also observe the safety and operating instructions of any other devices which are connected to the
product.
Miscellaneous
•
Consult an expert when in doubt about operation, safety or connection of the device.
•
Maintenance, modifications and repairs are to be performed exclusively by an expert or at a qualified
shop.
•
If you have questions which remain unanswered by these operating instructions, contact our technical
support service or other technical personnel.
4.
Operation
Ensure that the wires are connected to the electrical device with the correct polarity and
with a suitable adaptor. So you do not mix up the different wires you should use different
Version 10/12
cable colours (normally black for the negative terminal and red for the positive terminal).
Wires and adaptors must be approved for outside use and operation with a solar module.
Strip the insulation of the wire only far enough for the bare end to properly fit into the
screw terminal. Avoid making the bare wire ends too long, which would allow them to
come into contact with objects or body parts.
1.
Strip the insulation of the wires that you want to use for the connections only far enough for the bare end to
properly fit into the screw terminal.
2.
Loosen the screws of the screw terminals. Insert the bare wire ends into the lateral holes of the screw
terminals and tighten the screws again.
3.
Connect the wires to the electrical device. If required, use a suitable adaptor to connect the electrical
device.
4.
As soon as light falls on the module, it will start creating electric current and voltage.
5.
Position the solar module at a sunny spot or turn a 1000 W halogen lamp towards it (e.g. for experiments).
6.
During operation, put the solar module on a flat, clean surface.
7.
After use, loosen the screws of the screw terminals and remove the wires.
5.
Cleaning
Regularly clean the solar module, as its performance would otherwise decrease and the
surface could be irreversibly damaged.
•
To clean the surface, use a soft, antistatic and dry brush.
•
Under no circumstances use aggressive cleaning agents such as glass cleaners or chemical solutions to
clean the solar module, as the surface may otherwise be damaged.
6.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product according to the relevant statutory regulations.
7.
Technical data
Item no.
Nominal voltage:
Rated current:
Nominal power:
Efficiency:
Solar cell:
Operating temperature:
Operating humidity:
Connection:
Dimensions (W x H x D):
Weight:
Item no.
Nominal voltage:
Rated current:
Nominal power:
Efficiency:
Solar cell:
Operating temperature:
Operating humidity:
Connection:
Dimensions (W x H x D):
Weight:
Item no.
Nominal voltage:
Rated current:
Nominal power:
Efficiency:
Solar cell:
Operating temperature:
Operating humidity:
Connection:
Dimensions (W x H x D):
Weight:
© 2012 by Conrad Electronic SE.
11 04 43
11 04 54
18 V/DC
6 V/DC
150 mA
150 mA
2.7 W
0.9 W
15 %
15 %
polycrystalline
polycrystalline
-40 to +85 °C
-40 to +85 °C
10 – 90 %
10 – 90 %
Screw connection
Screw connection
200 x 200 x 3 mm
82 x 120 x 3 mm
185 g
47 g
11 04 56
11 06 44
3 V/DC
12 V/DC
250 mA
250 mA
0.75 W
3 W
15 %
15 %
polycrystalline
polycrystalline
-40 to +85 °C
-40 to +85 °C
10 – 90 %
10 – 90 %
Screw connection
Screw connection
62 x 120 x 3 mm
200 x 200 x 3 mm
36 g
185 g
11 06 83
11 06 84
6 V/DC
6 V/DC
450 mA
650 mA
2.7 W
3.9 W
15 %
15 %
polycrystalline
polycrystalline
-40 to +85 °C
-40 to +85 °C
10 – 90 %
10 – 90 %
Screw connection
Screw connection
200 x 200 x 3 mm
200 x 200 x 3 mm
203 g
203 g
These operating instructions are published by Conrad Electronic SE,
Klaus-Conrad-Straße 1, D-92240 Hirschau/Germany.
All rights including translation reserved. Reproduction by any method, e.g.
photocopy, microfilming, or the capture in electronic data processing systems
require the prior written approval by the editor. Reprinting, also in part, is prohibited.
The operating instructions reflect the current technical specifications at time of print.
We reserve the right to change the technical or physical specifications.
11 04 55
4 V/DC
250 mA
1 W
15 %
polycrystalline
-40 to +85 °C
10 – 90 %
Screw connection
82 x 120 x 3 mm
48 g
11 06 82
3 V/DC
850 mA
2.55 W
15 %
polycrystalline
-40 to +85 °C
10 – 90 %
Screw connection
200 x 200 x 3 mm
203 g
V5_1012_02-JU
