6.4 Precision adjustment of the stop for 90°
cross-cuts (Fig. 6/7)
Lower the machine head (4) and fix with the lock
pin (16).
Slacken the tightening screw (12).
Place the stop angle (a) between the saw blade
(5) and the rotary table (8).
Slacken the counter nut (19) and adjust the
setting screw (29) until the angle between the
saw blade (5) and the rotary table (8) equals 90°.
Re-tighten the counter nut (19) to fix the machine
in this setting.
Finally, check the position of the angle indicator
(11). If necessary, release the pointer with a
crosstip screwdriver, move to the 0° position of
the angle scale (15) and retighten the holding
screw.
6.5 Precision adjustment of the stop for 45° mitre
cuts (Fig. 8/9)
Lower the machine head (4) and fix with the lock
pin (16).
Fix the rotary table (8) in 0° position.
Undo the tightening screw (12) and use the
handle (2) to tilt the machine head (4) to the left
until it coincides at 45°.
Place the 45° stop angle (a) between the saw
blade (5) and the rotary table (8).
Slacken the counter nut (30) and adjust the
setting screw (18) until the angle between the
saw (5) and the rotary table (8) equals exactly
45°.
6.6 Dust bag (Fig. 2)
The saw is equipped with a bag (14) to collect
sawdust and chips. You can pull off the sawdust bag
(14) to the rear by pressing together the two clips. To
empty the bag, undo the zip at the bottom.
6.7 Replacing the saw blade (Fig. 1-4)
Pull out the power plug.
Swing up the machine head (4).
Press the release lever (1) and swing up the saw
blade guard (6) to the point where the recess in
the saw blade guard (6) is above the flange bolt
(b).
Press the saw shaft lock (13) with one hand
while holding the wrench (a) on the flange bolt
(b) with the other.
Firmly press on the saw shaft lock (13) and
slowly rotate the flange bolt (b) in clockwise
direction. The saw shaft lock engages after no
more than one rotation.
Now, using a little more force, slacken the flange
bolt (b) in clockwise direction.
Turn the flange screw (b) right out and remove
19.09.2008 13:31 Uhr Seite 13
the external flange (c).
Take the blade (5) off the inner flange and pull
out downwards.
Mount the new saw blade in reverse order and
fasten.
Important! The cutting bevel of the teeth, i.e. the
direction of rotation of the saw blade, has to
conform with the direction of the arrow marked
on the housing.
Clean the saw blade flanges thoroughly before
mounting the saw blade.
Before using the saw again, check that the safety
devices are in good working order.
Important: Every time that you change the saw
blade, check to see that it spins freely in the
groove of the turntable in both perpendicular and
45° angle settings.

7. Assembly and operation

7.1 Crosscut 90° and turntable 0° (Fig. 1)
Press the main switch (3) to turn on the saw.
Important. Place the material for sawing firmly on
the machine surface, to prevent it from moving
during the sawing process.
After switching on the saw, wait for the blade (5)
to reach its maximum speed.
Press the release lever (1) sideways and, using
the handle (2), apply steady and light downward
pressure to move the machine head through the
workpiece.
When the cut is completed, return the machine to
its top parking position and let go of the On/Off
switch.
Caution! A return spring causes the machine
head to rise automatically at the end of the cut.
Do not let go of the handle (2) as soon as the cut
is completed but steady the machine head and
allow it to rise slowly.
7.2 90° cross-cuts and 0°-45° rotary table (Fig. 8)
The crosscut saw can be used to make right and left
angular cuts of 0°- 45° in relation to the stop rail.
Lift the machine head (4) to its top position.
Release the turntable (8) by slackening the
locking grip (10).
Using the handle (2), set the turntable (8) to the
desired angle, i.e. the marking (a) on the
turntable must coincide with the desired angular
setting (17) on the stationary base plate (9).
Re-tighten the locking handle (10) in order to fix
the rotary table (8) in position.
Make the cut as described in Section 7.1).
