Perimeter wire layout
4
Lay the perimeter wire around the lawn area
4.7
and objects (4.8). Start from the docking station in an anti-clockwise direction.
This is important so your Indego cuts inside that area.
Use a mallet to insert the pegs in the ground (holding the wire in place)
and the 75 cm ruler provided to maintain the distance between them.
30 cm
Ensure:
▶ There is no loose wire as it
could be cut during mowing.
▶ The wire is flat to the
ground all the way.
Use additional pegs where
the wire is slack.
16
75 cm
~30 cm
▶ The wire is taut before ▶ Increase the number
placing the next peg (if you of pegs at a corner.
can place a couple of fingers
under the wire this is not
taut enough!).
Marking permanent
4.8
objects (1.2)
Mark out permanent objects you do not want
the mower to run over, e.g. roots, ponds, rocks.
This will prevent your Indego colliding with
objects, or going straight into them.
▶ A: Run the wire from the lawn perimeter
to the object.
▶ B: Continue round the object in a
clockwise direction. When going
around the object use more pegs,
so they are closer than 75 cm.
▶ C: Return the wire back to the perimeter.
Ensure the distance from the wire
around the object and lawn perimeter
is at least 75 cm.
Please ensure that the two parallel wires
leading to and from the marked object are as
close as possible by placing the wire under the
same side of the peg. This will make the wire
undetectable to your Indego. Please ensure
that the wires do not cross over eachother at
any point.
Remember to leave 30 cm around the object
to the wire!
If objects are less than 75 cm from the lawn
edge, surround the object when installing the
wire, leaving the object outside of the lawn
cutting area.
Check from time to time that the wire does
not become loose, attach the wire to the
ground with additional pegs if it does.
5 cm
When the perimeter wire has been
laid around the entire cutting area...
...peg the wire down within 10 cm
4.9
in line with the docking station as
illustrated.
▶ A: Cut the wire and strip 10–15 mm of insulation off.
▶ B: Connect it to the left hand (red) terminal.
▶ C: Clip over the backing cover.
After a few weeks, the wire will disappear under the grass.
Approximately 20 cm of lawn around the fixed object and
around the edge of the lawn will not be mown. For safety
reasons blades cannot reach up to the edge of the mower.
<75 cm
B
A
C
!
0 cm
1 m
10 cm
10 cm
1 m
A B C
