GB
Important!
The vibration value changes according to the area of
application of the electric tool and may exceed the
specified value in exceptional circumstances.

5. Before starting the equipment

Before you connect the equipment to the mains
supply make sure that the data on the rating plate are
identical to the mains data.
Always pull the power plug before making
adjustments to the equipment.
5.1 Safety guard (Fig. 1/Item 8)
The safety guard (8) protects the user from
accidentally touching the saw blade (12) and
nevertheless enables you a free view of the
cutting area.
5.2 Changing the saw blade (Fig. 2/Item 12)
Important!
Pull the mains plug before you fit or replace a saw
blade.
The teeth of the saw blade are very sharp!
Undo the screws (a) on the blade holder (13)
using the supplied Allen key.
Insert the saw blade (12) into the guide groove (b)
of the blade holder (13) as far as the stop.
Tighten the screws (a) with the supplied Allen
key.
The teeth on the saw blade must be pointing in
the direction of cutting. Check that the saw blade
is positioned in the guide groove (b) of the blade
holder (13) and the roller.
Check that the saw blade (12) is securely
mounted in the blade holder.
Follow the instructions above in reverse order to
remove the saw blade.
5.3 Setting the soleplate for miter cuts (Figs. 3-4)
Use the Allen key (4) to loosen the screws for the
soleplate (11) on the bottom of the adjustable
soleplate (7) (Figure 3).
Pull the soleplate (7) slightly forward. The
soleplate can now be swiveled a maximum 45° to
the left and right.
If the soleplate (7) is pushed back to the rear
again it will only function in the locking position at
0°, which is marked on the graduated scale for
the soleplate (9) (Figure 4).
However, the soleplate (7) is also easily set to
another angle. To do so, move the soleplate (7)
10
15.09.2008 13:17 Uhr Seite 10
forwards, set the desired angle and refasten the
screw securing the soleplate (11).
5.4 Adapter for dust extraction system (Figure 5)
The jigsaw is equipped with an adapter for the
vacuum cleaner connection. Place the adaptor onto
the jigsaw and secure by turning it. Any vacuum
cleaner can be connected to the extractor adaptor.
Check that the connections are air-tight. Dust created
when working may be dangerous. Be sure to observe
the safety instructions.
6. Operation
6.1 ON/OFF switch (Fig. 6/Item 3)
To switch on:
Press the ON/OFF switch
To switch off:
Release the ON/OFF switch
6.2 Locking button (Fig. 6/Item 2)
You can lock the ON/OFF switch (3) using the locking
button (2) when the equipment is in operation. To
switch off the equipment briefly hold down the
ON/OFF switch (3).
6.3 Electric speed selector (Fig. 6/Item 1)
You can pre-select the required speed with the speed
selector. Turn the speed selector in PLUS director to
increase the speed and turn the speed selector in
MINUS direction to reduce the speed. The suitable
stroke speed is dependent on the relevant material
and working conditions.
General rules for cutting speeds for metal cutting
work must be complied with here as well.
You can generally use a higher speed with fine saw
blades whilst coarser saw blades require lower
speeds.
low stroke speed (for steel)
medium stroke speed (for steel, soft metal,
plastic)
high stroke speed (for softwood, hardwood, soft
metal, plastic)
6.4 Making cuts
Ensure that the ON/OFF switch (3) is not
depressed. Only then should you connect the
mains plug to a suitable socket.
Do not switch on the jigsaw until you have fitted a
saw blade.
